Product Information
The AccelTex ATS-01050 is a 6 element dual band omni antenna for 2.4 and 5 GHz, with 4 dBi and 6 dBi gain. It has six N-type leads on 3 ft cables, handles up to 100 W and includes wall and pole mounts. Listed fits include Arista O-235E, Cisco 9124AXE, Fortinet 432F and Aruba AP-274.
Key Features
- Dual band 2.4 / 5 GHz
- 4 / 6 dBi omni
- 6 x N-type, 3 ft cables
- For Arista, Cisco, Fortinet, Aruba
- Indoor / outdoor
- Wall and pole mounts
Product Information
Brand: AccelTex Solutions
Manufacturer: AccelTex
Product Line: AccelTex Solutions
Compatibility Specs: Arista O-235E ¦ Cisco Catalyst 9124AXE ¦ Fortinet FortiAP 432F ¦ HPE Aruba AP-274
Packaged Quantity: 1
Color Category: White
Network and Communication
Antenna Gain: 4 dBi (for 2.4 - 2.5 GHz), 6 dBi (for 4.9 - 5.85 GHz)
Antenna Placement: Ceiling mountable, Flush mount, Indoor / outdoor, Pole mount, Surface mountable, Wall-mountable
Antenna Compatibility: 802.11ac, 802.11ax, 802.11n, Wi-Fi
Frequency Range: 2.4 - 2.5 GHz, 4.9 - 5.85 GHz
Signaling Type: Wi-Fi
Antenna Type: Antenna
Directivity: Omni-directional
Connectivity
Connectors: 6 x antenna - N connector
Technical Information
Impedance: 50 ohm
Antenna Features: Vertical polarization, VSWR < 2.0:1
Max Power: 100 watt
Physical Characteristics
Mounting Kit: Included
Materials: ASA plastic
Dimensions and Weight
Height: 2.8 inch
Width: 6.1 inch
Depth: 6.1 inch
Weight: 8.82 ounce
Included Items
Accessories Included: pole mount, Wall Mount
Cables: 6 x antenna cable - 3 ft
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
Service Activation: No
Not sure this antenna fits your hardware? Send us your access point or radio model and the DatorPro team will confirm the connector and compatibility before you order.
