Product Information
The AccelTex ATS-01123 is a 4 element dual band Wi-Fi patch antenna for 2.4 to 2.5 GHz and 5.1 to 5.85 GHz with 8 dBi gain, two horizontal and two vertical polarized elements and VSWR of 1.5:1. Beamwidths are 125 x 35 degrees at 2.4 GHz and 114 x 24 degrees at 5 GHz. It has four RP-SMA leads of 35.8 inches, 50 ohm impedance and an ABS housing rated IP66 for -40 to 70 C, and it flush mounts on a wall. It is listed for Cisco IW9165E, Extreme AP3000X, AP305CX and AP310E, Aruba AP-314, AP-324 and AP-334, and Mist AP32E and AP41E.
Key Features
- 4 element patch antenna
- 2.4 and 5 GHz, 8 dBi
- 4 RP-SMA leads, 35.8 in
- IP66, -40 to 70 C
- Flush wall mount
- Fits Cisco, Aruba, Mist, Extreme
Product Information
Brand: AccelTex
Manufacturer: AccelTex
Product Line: AccelTex Solutions
Product Type: Antenna
Category of Accessory: Antennas
Compatibility Specs: Cisco Catalyst IW9165E Rugged ¦ Extreme Networks AP3000X ¦ Extreme Networks ExtremeWireless AP305CX, AP310E ¦ HPE Aruba AP-314, AP-324, AP-334 ¦ Mist AP32E, AP41E
Packaged Quantity: 1
Color Category: White
Network and Communication
Antenna Gain: 8 dBi
Antenna Placement: Indoor, Outdoor
Antenna Compatibility: Wi-Fi
Frequency Range: 2.4 - 2.5 GHz, 5.1 - 5.85 GHz
Signaling Type: Wi-Fi
Features: 2 x horizontal polarization, 2 x vertical polarization, 4-element, Flush mount, Mounting holes, Wall Mountable
Connectivity
Antenna Cable Length: 35.8 inch
Connector Provided: 4 x RP-SMA
Technical Information
Impedance: 50 ohm
Antenna Form Type: Patch
Horizontal Beamwidth: 114° (at 5.1 - 5.85 GHz), 125° (at 2.4 - 2.5 GHz)
Vertical Beamwidth: 24° (at 5.1 - 5.85 GHz), 35° (at 2.4 - 2.5 GHz)
Voltage Standing Wave Ratio (VSWR): 1.5:1
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Physical Characteristics
Materials: ABS plastic
Dimensions and Weight
Height: 6.7 inch
Width: 12.6 inch
Depth: 1.4 inch
Certifications and Listing
Compliant Standards: IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n, IP66
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
Service Activation: No
