Product Information
The ADTRAN NetVanta 1561i-04 is a managed industrial L2+ switch with two Gigabit RJ-45 ports and two Gigabit SFP ports, rated from -40 to 75 C. It supports Ethernet OAM, CFM and ERPS ring protection, runs on 12 to 48 V DC, and mounts on a DIN rail or wall. It is a switch, not a router.
Key Features
- 2 x 10/100/1000 RJ-45, 2 x Gigabit SFP
- Managed L2+, CLI and web GUI
- Ethernet OAM, CFM, ERPS
- -40 to 75 C operation
- 12 to 48 V DC
- DIN rail and wall kits included
Product Information
Brand: ADTRAN
Manufacturer: ADTRAN
Product Line: ADTRAN NetVanta
Model: 1561i-04
Product Type: Switch
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Manageable: Yes
Remote Management: CLI, Web GUI
Features: Built-in DIP switch, Connectivity Fault Management (CFM), Ethernet OAM, Ethernet Ring Protection Switching (ERPS), Reset button
Connectivity
Ports: 4
Interface Provided: 1 x console RJ-45, 2 x 10/100/1000Base-T RJ-45, 2 x Gigabit SFP RJ-45/SFP
Power
Device Type: Internal power supply
Required Voltage: DC 12 - 48 volt
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 167 degree Fahrenheit
Operating Humidity: 0 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): DIN rail mountable, Wall-mountable
Status Indicators: Alarm, Port status, Power, Ring master, System
Dimensions and Weight
Height: 5.3 inch
Width: 2.4 inch
Depth: 5.1 inch
Weight: 2.2 lbs
Included Items
Included Accessories: DIN-rail mounting kit, Wall mounting kit
Cables: RJ-45 to DB-9 cable
Certifications and Listing
Compliant Standards: CSA NRTL, FCC Part 15 A
Warranty
Service Activation: No
