Product Information
The Advantech AQD-SD4U8GN32-SE is an 8 GB DDR4 unbuffered 260-pin SO-DIMM rated PC4-25600 (DDR4-3200) at 1.2 V, with on-die termination, 1024 x 8 chips, gold plated contacts and a 1.18 in height. The listing shows 1600 MHz, which is the base clock for this rating.
Key Features
- 8 GB DDR4-3200 SO-DIMM
- 1.2 V
- On-die termination
- Gold plated contacts
- Unbuffered
- Advantech part
Product Information
Compatible to OEM Part Numbers: Advantech AQD-SD4U8GN32-SE
Brand: Advantech
Manufacturer: IMC Networks
Product Line: Advantech
Product Type: Memory module
Packaged Quantity: 1
Memory and Processor
Memory Specification Compliance: PC4-25600
Memory Speed: 1600 megahertz
Memory Voltage: 1.2 volt
Registered or Buffered: Unbuffered
Chips Organization: 1024 x 8
Plating: Gold
RAM Features: On-Die Termination (ODT)
Module Height (inch): 1.18
Memory Type: DRAM
Ram Capacity: 8 GB
Memory Technology: DDR4 SDRAM
Form Factor (RAM): SO-DIMM 260-pin
Technical Information
Upgrade Type: Generic
Certifications and Listing
Compliant Standards: JEDEC, RoHS
Not sure this memory fits your system? Send us your server, workstation or laptop model and current memory setup, and the DatorPro team will confirm compatibility before you order.
