Product Information
The IMC Advantech EKI-1511-A is a 1 port serial device server with one DB-9 serial port for RS-232, RS-422 or RS-485 and one 10/100 RJ-45 port, at baud rates up to 230.4 Kbps. It supports virtual COM redirection plus TCP and UDP operating modes, up to 16 hosts in TCP client mode and up to five hosts on one serial port, plus peer to peer mode. It has 8 kV ESD protection on all serial signals, a metal case for wall or DIN rail mounting and web, Telnet, SNMP and SMTP management.
Key Features
- 1 serial port, DB-9
- RS-232, RS-422, RS-485
- 10/100 Ethernet
- Virtual COM, TCP and UDP
- 8 kV ESD protection
- Wall or DIN rail, metal
Product Information
Brand: Advantech
Manufacturer: IMC Networks
Product Line: Advantech
Model: EKI-1511
Product Type: Device server
Packaged Quantity: 1
Color Category: Black
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, RS-232, RS-422, RS-485
Network Standard: ARP, BOOTP, DHCP, DNS, ICMP/IP, TCP, UDP
Remote Management: HTTP, SMTP, SNMP, Telnet
Network Device: Baud rate: 230.4 Kbps
Operating System Required: Linux, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Server 2012
Features: 8KV ESD Protector, Flow control, Management Information Base (MIB) II, Metal housing, NTP support, Peer-to-peer, Web-based management
Connectivity
Interface Provided: 1 x 100Base-TX - RJ-45, 1 x serial - DB-9
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 167 degree Fahrenheit
Operating Humidity: 10 - 95% RH
Physical Characteristics
Form Factor: Wall / DIN rail mountable
Status Indicators: Link/activity, Power, Receive, Speed, Transmit
Dimensions and Weight
Height: 3.4 inch
Width: 1.8 inch
Depth: 0.8 inch
Weight: 4.48 ounce
Certifications and Listing
Compliant Standards #2: Directive 2002/95/EC, FCC Part 15 B Class A, UL/cUL
Compliant Standards: IEEE 802.3, IEEE 802.3u
Compliant Standards: Directive 2002/95/EC, FCC Part 15 B Class A, UL/cUL
Warranty
Limited Warranty: 5 Year
Service & Support Details: Limited warranty - 5 years
