Product Information
The Alcatel-Lucent SFP-10G-LR is a 10GBase-LR SFP+ optic for OmniSwitch switches. It runs at 10 Gbps on a 1310 nm wavelength over single mode fiber with an LC connector, reaching up to 6.2 miles (about 10 km), and supports digital diagnostics. Listed switches include OmniSwitch OS2360, OS6360, OS6450, OS6560, OS6570, OS6850 and OS6900 models.
Key Features
- 10GBase-LR long reach
- 1310 nm, LC single mode
- Reach up to 6.2 miles
- Digital diagnostics
- For OmniSwitch models
- SFP+ form factor
Product Information
Brand: Alcatel-Lucent
Manufacturer: Alcatel Internetworking
Product Line: Alcatel-Lucent
Product Type: SFP+ transceiver module
Compatibility Specs: P/N: OS2360-24, OS2360-24-IT, OS2360-24-UK, OS6360-24-IT, OS6360-24-UK, OS6360-P48, OS6450-48X-UK, OS6450-48X-US, OS6450-P24L-UK, OS6450-P24L-US, OS6450-P48L-UK, OS6450-P48L-US, OS6450-P48X-UK, OS6450-P48X-US, OS6450-U24X-US, OS6560-24Z24, OS6560-P24X4-ZZ, OS6560-P48X4-ZZ, OS6570-12-BP-D, OS6570-12-BP-EU, OS6570-BP-EU, OS6850-48L-IT, OS6850-48L-UK, OS6850E-48-UK, OS6900-V72, OS6900-V72-F, OS6900-V72-F-IT, OS6900-V72-F-UK, OS6900-V72-F-US, OS6900-V72-R, OS6900-V72-R-IT, OS6900-V72-R-UK, OS6900-V72-R-US, OS6900-X20, OS6900-X40-R-US, OS6900X48E, OS6900X48E-F-IT, OS6900X48E-F-UK, OS6900X48E-R, OS6900-X72-F-UK, OS6900-X72-F-US, OS6900-X72-R-UK, OS6900-X72-R-US
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet
Cable Type: Ethernet 10GBase-LR
Data Transfer Rate: 10 GBps
Max Transfer Distance: 6.2 miles
Optical Wave Length: 1310 nm
Features: Digital Diagnostics
Connectivity
Interface Provided: 1 x Ethernet 10GBase-LR - LC single-mode
Compatible Slots Required: 1 x SFP+
Left Connector SD Type: LC single-mode
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Module
Certifications and Listing
Compliant Standards: IEEE 802.3
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
