Product Information
This ASUS Pro WS unit is a fully modular ATX 3.1 / EPS12V unit with 80 PLUS Platinum efficiency, rated at 2200 W in the spec data. It provides four 16-pin 12VHPWR cables for multi GPU workstations and a full set of protections. The source description mentions 1600 W, so please confirm the wattage.
Key Features
- 2200 W output per spec data
- 80 PLUS Platinum, active PFC
- 4 x 16-pin 12VHPWR, 4 x 8-pin PCIe
- ATX12V 3.1 and EPS12V
- OCP, OVP, OPP, SCP, UVP and thermal protection
- Fully modular, dual ball bearing fan
Product Information
Brand: ASUS
Manufacturer: Asus Components
Product Line: ASUS
Model: Pro WS
Product Type: Power Supply
Subcategory: Power supplies
Packaged Quantity: 1
Color Category: Black
Power
PSU Form Factor: ATX
Modular: Yes
Power Factor Correction: Active Power Factor Correction (PFC)
Required Voltage: AC 100-240 volt
Power Device Features: Dual ball bearing cooling fan, Fully modular, Overcurrent protection, Overpower protection, Overvoltage protection, Protective PCB coating, Short-circuit protection, Thermal protection, Undervoltage protection
Power Output Connectors Details: 1 x power 24 pin ATX with detachable 4 pin section, 12 x 15 pin Serial ATA power, 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section, 3 x 4 pin internal power, 4 x 16 pin PCI Express power, 4 x 8 pin PCI Express power with detachable 2 pin section
Power Provided: 2200 watt
Form Factor (Power Device): Internal
Power Supply Compatibility: PC/Server
Provided Voltage: +3.3, +5, ±12 V, +5Vsb volt
Output Current: -12V - 0.8 A, +12V - 183.3 A, +3.3V - 25 A, +5V - 25 A, +5VSB - 3 A
80 PLUS Certification: 80 PLUS Platinum
Technical Information
Specification Compliance: ATX12V 3.1/ EPS12V
Dimensions and Weight
Height: 3.4 inch
Width: 5.9 inch
Depth: 6.9 inch
Weight: 4.7 lbs
Included Items
Cables: 2 x power 8 pin +12V with detachable 4 pin section modular cable 3.3 ft, 4 pin internal power cable 2.3 ft, 4 x 16-pin 12VHPWR power cable 2.5 ft, 4 x 8 pin PCI Express power with detachable 2 pin section modular cable 2.5 ft, 4 x Serial ATA cable 2 ft, AC input cable - external, Power 24 pin ATX with detachable 4 pin section modular cable 2 ft
Certifications and Listing
Compliant Standards: RoHS
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
