Product Information
The AXIS Camera Station S1232 (02537-001) is a 1U recording server with an Intel Xeon E, 16 GB RAM and 4 x 4 TB enterprise drives in factory RAID 5 across 4 hot swap bays. It runs Windows 10 IoT Enterprise 2021 LTSC with a 32 channel AXIS Camera Station license (64 validated channels), TPM 2.0, iDRAC and two gigabit ports. Static rails and two power cables included. TAA compliant.
Key Features
- 4 x 4 TB, RAID 5
- Xeon E, 16 GB RAM
- 32 channel license
- 4 hot swap bays
- TPM 2.0, iDRAC
- 1U rack, TAA
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: AXIS Camera Station
Model: S1232
Product Type: Server
Manufacturer Form Factor: Rack-mountable
Packaged Quantity: 1
Country: Argentina, Australia, Brazil, Europe, Japan, Korea, United Kingdom, United States
Network and Communication
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Operating System Edition: Windows 10 IoT Enterprise 2021 LTSC
Features: 64 validated video channels
Software Type: AXIS Camera Station (32 channels license)
Connectivity
Interface Provided: 1 x (1 front) (iDRAC Direct port), 1 x (1 rear) (iDRAC dedicated port), 1 x serial (1 rear), 1 x USB 2.0 (1 in front), 1 x USB 2.0 (1 rear), 1 x USB 3.2 (1 rear), 1 x VGA (1 rear), 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear)
Ethernet Ports: 2 x Gigabit Ethernet
Memory and Processor
Removable Hard Drive: Hot-swap
Hot-Swap Bays: 4
Hard Drive Features: Enterprise, RAID 5 - factory configured
Storage Controller Type: RAID
RAID Levels: RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
Processor Brand: Intel
Processor Type: Xeon E
Processors Installed: 1
RAM Installed: 16 GB
Hard Drive Capacity: 4 TB
Drive Type: No optical drive
Hard Drive Interface Type: HDD
Optical Drive Type: No optical drive, None
Optical Drive Type (2nd): None
Technical Information
Configuration Features: 2 x 8 GB
Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip
Operating System: Windows 10 IoT
Operating System Platform: Windows
Server Storage Bays: Hot-swap
Printer Product Type: None
Min Operating Temperature: 50 degree Fahrenheit
Max Operating Temperature: 95 degree Fahrenheit
Operating Humidity: 8 - 80% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Installed Quantity: 4
Dimensions and Weight
Height: 1.7 inch
Width: 23.6 inch
Depth: 19 inch
Weight: 28.44 lbs
Included Items
Included Accessories: Static rails
Cables: Power cable (C13-C14) (2 pcs.)
