Product Information
The Axis D4100-VE Mk II (03105-001) is an outdoor network strobe siren with an LED strobe up to 893 lumens, a 110 dB maximum SPL and a 150 degree coverage pattern, for wall or ceiling mounting. It runs on PoE with AXIS Edge Vault and works from -40 to 60 C. White, TAA compliant. It is a deterrent device, not a camera.
Key Features
- Strobe and siren
- Up to 893 lumens
- 110 dB max SPL
- PoE powered
- Outdoor, TAA
- Wall or ceiling mount
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: Axis
Model: D4100-VE Mk II
Product Type: Alarm light / siren
Packaged Quantity: 1
Color: NCS S 1002-B, White
Color Category: White
Network and Communication
Features #2: 150° coverage pattern, Ceiling mountable, LED strobe light, Max SPL 110 dB, Maximum 893 lumens, Wall Mountable
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet
Wired Protocol: 10/100 Ethernet
Authentication Method: EAP-TLS, PEAP-MSCHAPv2, X.509 certificates
Features: ARP support, Axis device ID, Axis Edge Vault, Brute force delay protection, CDP support, CIFS/SMB support, DDNS (Dynamic Domain Name Service), DHCPv4/v6 support, Digest authentication, DNS/DNSv6 support, DTMF support, HTTP support, HTTP/2 support, HTTPS support, ICMPv4/ICMPv6 support, IGMPv1/v2/v3 support, Internet Control Message Protocol (ICMP), IPv4 support, IPv6 support, LLDP support, mDNS, MQTT support, MQTT v3.1.1 support, NTP support, NTS support, Password protection, QoS Layer 3 DiffServ support, RSTP, RTCP support, RTP support, Secure Boot, Signed OS, SIP support, SMTP support, SNMP v1/v2c/v3 (MIB-II) support, SRTP/RTSPS support, SSH support, TCP support, Trusted Platform Module (TPM), UDP support, UPnP, VAPIX support, ZeroConf support
Features: 150° coverage pattern, Ceiling mountable, LED strobe light, Max SPL 110 dB, Maximum 893 lumens, Wall Mountable
Connectivity
Interfaces: 4-pin terminal block, LAN
Power
Power Source: PoE
Memory and Processor
Processor Brand: NXP
Processor Type: i.MX 8M Nano UL
RAM Installed: 1 GB
Flash Memory Installed: 1 GB
Technical Information
Environment: Outdoor
Touchscreen: No
Physical Characteristics
Materials: Aluminum, Plastic
Dimensions and Weight
Height: 6.7 inch
Width: 6.7 inch
Depth: 2.6 inch
Weight: 2.2 lbs
Included Items
Included Accessories: Cable gaskets, Connector guard, Terminal connector
Certifications and Listing
Compliant Standards: AS/NZS CISPR 32 Class A, BFR-free, CAN/CSA C22.2 No. 62368-1 Third Edition, CISPR 32 Class A, Directive 2015/863, EN 50121-4, EN 50130-4, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, EN/IEC 63000:2018, ETSI EN 303 645, FCC Part 15 B Class A, FIPS 140, ICES, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC/EN 60529 IP66, IEC/EN 62262 IK10, IEC/EN/UL 62368-1 Third Edition, IEC/EN/UL 62471 Risk Group 1, IEEE 802.1ar, IEEE 802.1x, IEEE 802.3at Type 2, IK10, IP66, IPv6, KC, KS C 9832 Class A, KS C 9835, MIL-STD-810H, NEMA 250 Type 4X, NEMA Type 4X, NIST SP500-267, PVC-free, RCM, REACH 1907/2006/CE, ROHS Directive 2011/65/EU, UL/cUL, USGv6, VCCI, VCCI Class A, WEEE
TAA Compliant: Yes
