Product Information
The AXIS F4105-LRE is a rugged, discreet dome sensor unit for the AXIS F91 main units, built to handle shock, vibration and water. It has a 1/2.8 inch sensor with Forensic WDR and night vision, an M12 lens and draws 3.7 W. Spec lists 1080p at 60 fps and 720p at 180 fps, while the text says 1080p at 30 fps and 720p at 60 fps, please confirm. White.
Key Features
- Sensor unit for AXIS F91
- 1080p and 720p modes
- Forensic WDR, night vision
- Shock and vibration resistant
- M12 lens, lens tool included
- 3.7 W, white
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: AXIS
Model: F4105-LRE
Packaged Quantity: 1
Color: NCS S 1002-B, White
Color Category: White
Country: Argentina, Australia, Brazil, China, European Union, India, Japan, Korea, United Kingdom, United States
Network and Communication
Connectivity Technology: Wired
Features: Forensic WDR, Infrared-cut filter, Ruggedized
Connectivity
Ports: SMA
Power
Power Consumption Operational: 3.7 watt
Technical Information
Video Capture: 1280 x 720 @ 180 fps, 1920 x 1080 @ 60 fps
Camera Type: Network surveillance camera
Tilt: 120
Panning Range (degree): -180 to +180
Video Modes: 1080p, 720p
Image Sensor Size: 1/2.8"
Image Sensor Type: PS RGB CMOS
Night Vision: Yes
Digital Video Capture Resolution: 1280 x 720, 1920 x 1080
Max Frame Rate: 180 frames per second
Touchscreen: No
Max Video Resolution: 1920 x 1080
Physical Characteristics
Camera Mechanical Design: Fixed
Dimensions and Weight
Height: 4.4 inch
Width: 4.4 inch
Depth: 3.3 inch
Weight: 20.81 ounce
Included Items
Included Accessories: Lens tool
Certifications and Listing
Compliant Standards: AS/NZS CISPR 32 Class B, BFR-free, CAN/CSA C22.2 No. 62368-1 Third Edition, CFR free, ECE R10 Rev.06, EN 50121-3-2, EN 50121-4, EN 50155:2017 Class OT2/ST2, EN 50498, EN 55032 Class B, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), IEC 60068-2-27, IEC 60068-2-64, IEC 60529 IP66, IEC 60529 IP67, IEC 60721-3-5 Class 5M3, IEC 62236-4, IEC/EN 62262 IK10, IEC/EN 62471, IEC/EN/UL 62368-1, IP6K9K, IS 13252, ISO 20653, KS C 9832 Class B, KS C 9835, NEMA250 Type 4X, NFPA 130, PVC-free, UN ECE R118, VCCI Class B
Not sure this camera fits your setup? Send us the model of your NVR, VMS or current cameras and how you plan to mount and power it, and the DatorPro team will help you confirm compatibility before you order.
