Product Information
The AXIS M3128-LVE is an 8 MP (4K) turret recording 3840 x 2160 at 15 fps with a 110 degree view, for indoor or outdoor use. It has a deep learning processing unit for AI analytics, OptimizedIR up to 66 ft, two way audio with speaker pairing and Axis Edge Vault, and runs on PoE Class 3. Vandal and weatherproof, white. TAA compliant.
Key Features
- 4K, 8 MP
- 110 degree view
- AI analytics, DLPU
- IR up to 66 ft
- Two way audio
- PoE, TAA compliant
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: AXIS
Model: M3128-LVE
Packaged Quantity: 1
Color: White
Color Category: White
Country: Argentina, Australia, Brazil, China, Europe, Japan, South Korea, United Kingdom, United States
Network and Communication
Connectivity Technology: Wired
Features: -95° / +95° rotation, 110° field of view, Adaptive Bitrate (ABR), AI Analytics, AI-powered, Ambarella CV25 SoC, Axis Edge Vault, Built-in IR illuminator, Deep learning processing unit (DLPU), IR Corrected lens, OptimizedIR, PVC Free, Repaintable, Secure Boot, Variable Bit Rate (VBR), Wide Dynamic Range (WDR), Zipstream technology
Connectivity
Network Interface: Ethernet 10Base-T/100Base-TX
Protocols: ARP, CDP, CIFS, DDNS, DHCPv4, DHCPv6, DNS, DNSv6, FTP, HTTP, HTTPS, ICMP, ICMPv4, ICMPv6, IGMP, IGMPv2, IGMPv3, IPv4, IPv6, LLDP, MDNS, MQTT, NTP, NTS, QOS, RTCP, RTP, RTSP, RTSPS, SFTP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SRTP, SSH, TCP, TLS, UDP, UPnP
Ports: LAN/power - RJ-45
Memory and Processor
Memory Cards Supported: microSD Card
RAM Installed: 2048 megabyte
Flash Memory Installed: 512 megabyte
Technical Information
Angular Field of View (H, Max, Degree): 110
Angular Field of View (V, Max, Degree): 60
Infrared Distance: 66 ft
Infrared LEDs: Yes
Max Focal Length: 2.9 millimetre
Optical Zoom: 5.8
Sensor Pixels Total (H): 3840
Sensor Pixels Total (V): 2160
Tilt: 0 to 60
Motion Detection: Yes
Panning Range (degree): -180 to +180
Camera Iris: Fixed iris
Lens Mount: M12 mount
Minimum Illumination: 0.05 lux - B&W - F1.2 - 50 IRE, 0.22 lux - color - F1.2 - 50 IRE
Total Pixels: 8,000,000 pixels
Video Modes: 4K
Image Sensor Size: 1/2.8"
Image Sensor Type: PS RGB CMOS
Lens Aperture: F/2.0
Min Focal Length: 0.5 metre
Sensor Size (metric): 9.1 mm (1/2.8")
Digital Video Capture Resolution: 160 x 90, 3840 x 2160
Max Frame Rate: 15 frames per second
Shutter Speed (Max): 2 second (time unit)
Shutter Speed (Min): 1/71500 second (time unit)
Video Formats: H.264, H.265, MJPEG
Video Input: Color
Audio Support: Yes
Audio Formats: AAC-LC, G.711, G.726, LPCM
Audio Support Features: Speaker pairing, Two-way audio capability
Touchscreen: No
Max Video Resolution: 3840 x 2160
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Physical Characteristics
Indoor/Outdoor: Indoor, Outdoor
Protection: Vandal / weatherproof
Form Factor: Turret
Camera Mechanical Design: Pan / tilt / zoom
Dimensions and Weight
Height: 3.7 inch
Width: 4 inch
Depth: 4 inch
Weight: 13.76 ounce
Included Items
Included Accessories: Cable gaskets, Connector guard, Owner authentication key
