Product Information
The AXIS P1245 Mk II (02857-001) is a modular indoor camera with a small sensor unit on a 26 ft cable, recording 1080p at 30 fps through a 2.8 mm M12 lens with a 111 degree view. It has a deep learning processing unit for AXIS Object Analytics, Live Privacy Shield, Forensic WDR, audio through portcast and AXIS Edge Vault. Listed as TAA compliant.
Key Features
- Modular sensor unit
- 1080p at 30 fps
- 2.8 mm, 111 degrees
- 26 ft sensor cable
- AXIS Object Analytics
- Listed TAA compliant
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: AXIS P12 Series
Model: P1245 Mk II
Packaged Quantity: 1
Color: NCS S 1002-B, White
Color Category: White
Country: Argentina, Australia, Brazil, China, Europe, Japan, Korea, United Kingdom, United States
Network and Communication
Connectivity Technology: Wired
Encryption: TLS 1.2, TLS 1.3
Features: Adaptive Bitrate (ABR), Axis device ID, Axis Edge Vault, Brute force delay protection, Deep learning processing unit (DLPU), Digest authentication, Dynamic text, Forensic WDR, Image overlay, Level grid, Modular, Multi-Bitrate (MBR), ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Password protection, Pixel Counter Support, Polygon privacy mask, Scene metadata, Secure Boot, Secure keystore, Signed firmware, Signed video, Variable Bit Rate (VBR), Zipstream technology
Software Type: AXIS Live Privacy Shield, AXIS Object Analytics, AXIS Video Motion Detection
Connectivity
Network Interface: Ethernet 10Base-T/100Base-TX
Protocols: ARP, Bonjour, CDP, CIFS, DDNS, DHCPv4, DHCPv6, DNS, DNSv6, FTP, HTTP, HTTP/2, HTTPS, ICMP, ICMPv4, ICMPv6, IGMP, IGMPv2, IGMPv3, IPv4, IPv6, LLDP, MQTT, NTP, NTS, QOS, RTCP, RTP, RTSP, RTSPS, SFTP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SRTP, SSH, Syslog, TCP, TLS, UDP, UPnP, USGv6, Zeroconf
Ports: LAN - RJ-45, Sensor unit - RJ-12
Memory and Processor
Memory Cards Supported: microSD Card, microSDHC Card, microSDXC Card
RAM Installed: 1 GB
Flash Memory Installed: 512 megabyte
Technical Information
Motion Detection: Yes
Angular Field of View (H, Min, Degree): 111
Angular Field of View (V, Min, Degree): 61
Camera Iris: Fixed iris
Lens Mount: M12 mount
Min Focus Distance: 7.9 inch
Minimum Illumination: 0.2 lux - color - F2.0 - 50 IRE
Video Modes: 1080p
Image Sensor Size: 1/2.9"
Image Sensor Type: PS RGB CMOS
Lens Aperture: F/2.0
Min Focal Length: 2.8 millimetre
Sensor Size (metric): 8.8 mm (1/2.9")
Digital Video Capture Resolution: 1024 x 640, 1024 x 768, 1920 x 1080, 480 x 360, 640 x 360, 640 x 400
Max Frame Rate: 30 frames per second
Shutter Speed (Max): 1/16500 second (time unit)
Shutter Speed (Min): 1/5 second (time unit)
Focal Length Control: Fixed focal
Video Formats: AVC, H.264B, H.264H, H.264M, H.265, HEVC, MJPEG, MPEG-4 Part 10, MPEG-H Part 2
Video Input: Color
Audio Support: Yes
Audio Support Features: Audio through portcast technology
Touchscreen: No
Max Video Resolution: 1920 x 1080
Min Operating Temperature: -4 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 10 - 85% RH (non-condensing)
Physical Characteristics
Indoor/Outdoor: Indoor
Camera Mechanical Design: Fixed
Included Items
Included Accessories: 2 locking nuts, Owner authentication key
Cables: 1 x sensor cable - external - 26 ft
