Product Information
The AXIS Q6020-E (02957-001) is an outdoor dome with four 5 MP sensors (2592 x 1944 each) on 3.7 mm lenses for 360 degree coverage, with remote focus. It runs AXIS Object Analytics on a deep learning processing unit, uses Lightfighter, WDR and Zipstream, and is vandal and weatherproof. Listed as PTZ with night vision. Backed by a 5 year limited warranty.
Key Features
- 4 x 5 MP sensors
- 360 degree coverage
- Remote focus
- AXIS Object Analytics
- Vandal, weatherproof
- 5 year limited warranty
Product Information
Brand: Axis
Manufacturer: Axis Communications
Product Line: AXIS Q60 Series
Model: Q6020-E
Packaged Quantity: 1
Color Category: Black, White
Country: Brazil, Japan, Korea, United States
Network and Communication
Connectivity Technology: Wired
Features: Axis Edge Vault, AXIS Object Analytics, Deep learning processing unit (DLPU), Lightfighter technology, Metadata, Remote focus, Wide Dynamic Range (WDR), Zipstream technology
Connectivity
Ports: LAN/power - RJ-45
Technical Information
Focus Modes: Automatic
Camera Type: Network surveillance camera
Motion Detection: Yes
Angular Field of View (H, Min, Degree): 360
Angular Field of View (V, Min, Degree): 84
Minimum Illumination: 0.03 lux - B&W, 0.06 lux - color
Total Pixels: 4 x 5,000,000 pixels
Image Sensor Size: 1/1.7"
Image Sensor Type: PS CMOS
Min Focal Length: 3.7 millimetre
Sensor Size (metric): 14.9 mm (1/1.7")
Night Vision: Yes
Digital Video Capture Resolution: 2592 x 1944
Max Frame Rate: 30 frames per second
Video Formats: H.264, H.265
Video Input: Color
Touchscreen: No
Max Video Resolution: 2592 x 1944
Min Operating Temperature: -58 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Physical Characteristics
Indoor/Outdoor: Outdoor
Protection: Vandal / weatherproof
Form Factor: Dome
Camera Mechanical Design: Pan / tilt / zoom
Warranty
Limited Warranty: 5 Year
Service & Support Details: Limited warranty - 5 years
