Product Information
Black Box's LGB1110A is an L2+ managed switch with ten Gigabit RJ-45 ports, two of which share with SFP slots for 100M or 1G fiber. It offers 20 Gbps of switching capacity, ACLs, IP source guard and Energy Efficient Ethernet, and it is TAA compliant.
Key Features
- 10 x 10/100/1000 RJ-45 ports
- 2 x shared Gigabit SFP slots
- 20 Gbps switching, 14.88 Mpps
- L2+, ACL, IP source guard
- Desktop or rack mount
- TAA compliant
Product Information
Brand: Black Box
Manufacturer: Black Box
Product Line: Black Box
Model: Gigabit Ethernet Managed Switch
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Advanced Switching: Layer 2+
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, Telnet
Routing Protocol: IGMP, IGMPv2, IGMPv3
Authentication Method: RADIUS, Secure Shell (SSH)
Encryption: SSL
Performance: Forwarding bandwidth: 14.88 Mpps, Switching capacity: 20 Gbps
Capacity: Jumbo frame size: 9216, MAC address entries: 8000
MAC Address Table Size: 8K entries
Jumbo Frame Support: 9216 bytes
Features: Access Control List (ACL) support, Auto-sensing per device, Cable Diagnostics Function, DHCP client, DHCP server, Energy Efficient Ethernet, IP source guard, IPv4 support, IPv6 support, LLDP support, Quality of Service (QoS), sFlow, SNTP support, Syslog support, Tagged VLAN, VLAN support
Connectivity
Ports: 10
Port Quantity: 10
Port Type: 10/100/1000
Ports (2nd) Quantity: 2
Ports Type (2nd): Shared Gigabit SFP
Interface Provided: 1 x console RJ-45, 10 x 1000Base-T RJ-45, 2 x Gigabit LAN SFP
Power
Device Type: Internal power supply
Frequency: 50 - 60 hertz
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.5 inch
Width: 8.7 inch
Depth: 5.3 inch
Weight: 3.09 lbs
Included Items
Cables: 1 x console cable
Certifications and Listing
Compliant Standards: IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3az, UPnP
Compliant Standards: FCC Part 15 A
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
TAA Compliant: Yes
Warranty
Service Activation: No
