Product Information
Black Box's SW1040A is a Layer 1 A/B switch that moves one CAT6 link between two paths. Use the front push button, or the rear 6 position terminal strip for remote dry contact control. It is tested to 1,000,000 cycles. This is a physical A/B switch, not an Ethernet network switch.
Key Features
- 1 x 2 Layer 1 A/B switching, CAT6
- 3 x RJ-45 ports
- Front push button control
- Remote dry contact via terminal block
- Tested to 1,000,000 cycles
Product Information
Brand: Black Box
Manufacturer: Black Box
Product Line: Black Box Remotely Controlled Layer 1 A/B Switch
Model: CAT6, 1 x 2
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Connectivity
Interface Provided: 3 x LAN RJ-45, Remote control: 1 x 6 pin terminal block
Power
Device Type: External power adapter
Frequency: 50 - 60 hertz
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Status Indicators: Status
Dimensions and Weight
Height: 2.5 inch
Width: 6.3 inch
Depth: 6.3 inch
Weight: 3.97 lbs
Certifications and Listing
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
