Product Information
The Bosch NPD-6001C-E is an outdoor midspan that delivers up to 60 W at 54 V DC under 802.3bt Type 3. It is IP67 dustproof and water resistant, works from -40 to 185 °F, is wall mountable and includes a waterproof gland. White finish.
Key Features
- 1 x Gigabit PoE output, up to 60 W
- IEEE 802.3bt Type 3
- IP67, -40 to 185 °F
- Wall mountable
- Waterproof gland included
Product Information
Brand: Bosch
Manufacturer: Bosch
Product Line: Bosch
Model: NPD-6001C-E
Product Type: PoE Injector
Subcategory: Power converters, splitters and accessories
Packaged Quantity: 1
Color: White
Color Category: White
Country: Worldwide
Network and Communication
Features: Dustproof, Water-resistant
Connectivity
Interface Provided: 1 x Gigabit LAN (PoE) - RJ-45
Power Over Ethernet (PoE): PoE
Output Connector Quantity: 1
Power
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Device Features: 6 kV surge protection, Outdoor
Input Connector Type: RJ-45
Power Provided: 60 watt
Form Factor (Power Device): Wall mountable
Max Input Current: 2 ampere
Voltage Required Margin: + 10% / - 10%
Surge Suppression: Yes
Provided Voltage: DC 54 volt
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 185 degree Fahrenheit
Operating Humidity: 95% RH (non-condensing)
MTBF: 200,000 Hours
Dimensions and Weight
Height: 2.4 inch
Width: 5.5 inch
Depth: 6.7 inch
Weight: 3.09 lbs
Included Items
Included Accessories: Waterproof gland
Certifications and Listing
Compliant Standards: IEEE 802.3bt Type 3
Compliant Standards: EN 55032 Class B, EN 60529, EN 61000-4-5 Class 5, EN55024, FCC Part 15 B, IEEE 802.3bt, IP67, NEMA 250 Type 4X, Plug and Play, RoHS, UL 60950-22, UL/IEC/EN 60950-1 (Ed. 2), VCCI, WEEE
ENERGY STAR Certified: No
Warranty
Service Activation: No
Not sure this fits your setup? Send us the model of the device you need to power or connect and the DatorPro team will confirm compatibility before you order.
