Product Information
The Cisco Business 240AC (CBW240AC-B) is a Wi-Fi 5 Wave 2 access point with 4x4 MU-MIMO and beamforming for high density small offices. It supports mesh, VLANs and 802.1x, has two Gigabit PoE+ ports and draws about 13.2 W.
Key Features
- Wi-Fi 5 Wave 2, 4x4 MU-MIMO
- Beamforming, mesh support
- 2 x Gigabit RJ-45 (PoE+)
- 802.1x, RADIUS, VLAN
- About 13.2 W
- 1 GB RAM, 256 MB flash
Product Information
Brand: Cisco
Manufacturer: Cisco Systems
Product Line: Cisco Business
Model: 240AC
Product Type: Wireless access point
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Authentication Method: EAP-FAST, Extensible Authentication Protocol (EAP), MS-CHAP v.2, RADIUS
Encryption: AES, PEAP, TLS, TTLS, WPA2, WPA3
Capacity: VLANs supported: 16, Wireless clients per Wi-Fi radio: 200, Wireless clients: 400
Wireless LAN: 802.11a/b/g/n/ac Wave 2
Network Band: 2.4 GHz, 5 GHz
Network Device: Maximum data rate (5 GHz): 1733 Mbps
Antennas: 2
Antenna Form Factor: Internal
Directivity: Omni-directional
Features: 4x4 MU-MIMO technology, 802.1x authentication, Authentication, Authorization and Accounting (AAA), Beamforming technology, Ceiling mountable, DFS support, Manageable, Mesh networking, RADIUS support, VLAN support, Wi-Fi Multimedia (WMM) support
Connectivity
Interface Provided: 2 x 1000Base-T (PoE+) - RJ-45
Power Over Ethernet (PoE): PoE+
Power
Power Consumption Operational: 13.2 watt
Memory and Processor
RAM Installed: 1 GB
Flash Memory Installed: 256 megabyte
Technical Information
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: External
Status Indicators: Status
Dimensions and Weight
Height: 1.5 inch
Width: 7 inch
Depth: 7 inch
Weight: 15.17 ounce
Certifications and Listing
Compliant Standards: ARPANSA, AS/NZS 2772, AS/NZS 4268:2017, AS/NZS 60950-1, AS/NZS CISPR 32:2015, CAN/CSA-C22.2 No. 60950-1, CECP, CISPR 24:2010, CISPR 32:2015, CNS 13438, EN 300 328 V2.1.1, EN 301 489-1 V2.1.1:2017, EN 301 489-17 V3.1.1 (2017), EN 301 893 V2.1.1, EN 50385, EN 55032:2012+AC:2013 Class A, EN 55032:2015, EN 55035, EN 60601-1-1, EN 60950-1, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 62209-1, EN 62209-2, EN55024, ICES-003 issue 6 Class B, IEC 60950-1, KN 489-1, KN 489-17, KN 61000-3-2, KN 61000-3-3, KN32, LP0002, NRCAN, QCVN, RSP-100, RSS-102, RSS-247, RSS-GEN, SRRC, TCVN 7189, UL 2043, UL 60950-1, VCCI V-3
Compliant Standards: IEEE 802.11a, IEEE 802.11ac Wave 1, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - replacement - lifetime
Service Activation: No
Not sure this fits your network? Send us your controller, switch or current access point model and the DatorPro team will confirm compatibility before you order.
