Product Information
The Cisco Catalyst 9800-L-C (C9800-L-C-K9) is a 1U wireless controller running Cisco IOS XE, built for intent based networking with Cisco DNA. This copper version has 4 x 1/2.5GBase-T RJ-45 ports and 4 x 10 GbE ports, plus RJ-45 console, RJ-45 management, mini-USB, USB Type A and a redundancy port. It handles up to 250 access points, 5,000 clients, 4,096 VLANs and 4,096 WLANs with 5 Gbps throughput, and supports Wi-Fi 6 access points. Management covers HTTPS, SNMP v1/v2c/v3, SSH and RMON, with WPA2, EAP and RADIUS security. It is rated at 110 W with 86.9 W typical use.
Key Features
- Up to 250 APs, 5,000 clients
- 5 Gbps throughput
- 4 x 1/2.5G RJ-45
- 4 x 10 GbE ports
- Cisco IOS XE
- 1U rack mount
Product Information
Brand: Cisco
Manufacturer: Cisco Systems
Product Line: Cisco Catalyst
Model: 9800-L Wireless Controller
Product Type: Network management device
Packaged Quantity: 1
Color Category: Silver
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: 10 Gigabit Ethernet, Gigabit Ethernet, IEEE 802.11ac Wave 1, IEEE 802.11ac Wave 2
Network Standard: ARP, Bonjour, BOOTP, DHCP, ICMP/IP, IPSec, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS, RMON, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
Authentication Method: Extensible Authentication Protocol (EAP), RADIUS
Encryption: AES, CCM, CCMP, CRL, ESP, IKE, PKI, SSL, TLS, Triple DES, WPA, WPA2
Capacity: Maximum number of access points: 250, Maximum number of clients: 5000, VLANs supported: 4096, Wireless LANs: 4096
Wireless LAN: 802.11a/b/g/n/ac Wave 2/ax
Network Device: Throughput: 5 Gbps
Operating System Edition: Cisco IOS XE
Features: CAPWAP support, Datagram Transport Layer Security (DTLS), Internet Control Message Protocol (ICMP), IPv6 support, RADIUS support, SNTP support, Syslog support, User Datagram Protocol (UDP), VLAN support, Wi-Fi Multimedia (WMM) support
Connectivity
Interface Provided: 1 x console - RJ-45, 1 x management - RJ-45, 1 x mini-USB - Type B, 1 x redundancy, 1 x USB - Type A, 4 x 1/2.5GBase-T - RJ-45, 4 x 10Gb Ethernet - RJ-45
Power
Device Type: External power adapter
Frequency: 50/60 hertz
Power Consumption Operational: 86.9 watt
Power Provided: 110 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 95% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Status Indicators: Link/activity, Power, System
Dimensions and Weight
Height: 1.6 inch
Width: 8.5 inch
Depth: 9.1 inch
Weight: 3.95 lbs
Certifications and Listing
Compliant Standards #2: IEEE 802.11a, IEEE 802.11ac Wave 1, IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11w, IEEE 802.1AX, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Compliant Standards: AS/NZS 60950-1, AS/NZS CISPR 22, CAN/CSA-C22.2 No. 60950-1, CISPR 22, CNS 13438, EN 300 386, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN50082-1, EN55022, FCC CFR47 Part 15, ICES-003, IEC/EN 60950-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEEE 802.1x, IEEE 802.3, KN32, UL/CSA60950-1, VCCI
Compliant Standards: IEEE 802.11a, IEEE 802.11ac Wave 1, IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11w, IEEE 802.1AX, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
Not sure this device fits your network? Send us your current equipment models and what you need to monitor or manage, and the DatorPro team will confirm compatibility before you order.
