Product Information
The Cisco Catalyst IE3400 (IE-3400-8T2S-E) is a rugged industrial switch with eight Gigabit RJ-45 ports and two Gigabit SFP ports, licensed with Network Essentials. It runs from -40 to 158 F, supports redundant power and IEEE 1588 CIP Sync, and mounts on a DIN rail with alarm inputs.
Key Features
- 8 x 10/100/1000 RJ-45 ports
- 2 x Gigabit SFP ports
- Network Essentials, 802.1x, ACL, DHCP snooping
- IEEE 1588 CIP Sync
- -40 to 158 F, redundant power
- DIN rail mount, alarm I/O
Product Information
Brand: Cisco
Manufacturer: Cisco Systems
Product Line: Cisco Catalyst
Model: IE3400 Rugged Series
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: HTTP, NTP, RMON, SCP, SNMP 1, SNMP 2, SNMP 3, SSH, Telnet, TFTP
Routing Protocol: IGMP, IGMPv2, IGMPv3, MSTP, RSTP, STP
Authentication Method: RADIUS, Secure Shell (SSH), TACACS+
Capacity: ACL: 1500, IGMP groups: 1000, Queues: 8, STP instances: 128, VLAN IDs: 256
MAC Address Table Size: 8K entries
Features: 802.1x authentication, Access Control List (ACL) support, ARP support, BOOTP support, BPDU Guard, Broadcast Storm Control, CIP Sync (IEEE 1588), DHCP relay, DHCP server, DHCP snooping, DHCP support, DiffServ support, Dying Gasp, Dynamic ARP Inspection (DAI), Fanless, Guest VLAN, IGMP filtering, IGMP querier, IGMP snooping, Internet Control Message Protocol (ICMP), IP source guard, IPv4 support, IPv6 support, LACP support, LLDP support, Management Information Base (MIB), Multicast Storm Control, Per-VLAN Spanning Tree Plus (PVST+), Port Security, Precision Time Protocol (PTP), Quality of Service (QoS), RADIUS support, Remote Switch Port Analyzer (RSPAN), Resilient Ethernet Protocol (REP), SmartPort technology, Spanning Tree Protocol (STP) support, Syslog support, Uni-Directional Link Detection (UDLD), Unicast Storm Control, User Datagram Protocol (UDP), VLAN Trunking Protocol (VTP) v.2, VLAN Trunking Protocol (VTP) v.3, Voice VLAN
Edition: Network Essentials
Connectivity
Ports: 10
Port Quantity: 8
Port Type: 10/100/1000
Ports (2nd) Quantity: 2
Ports Type (2nd): Gigabit SFP
Interface Provided: 1 x alarm, 1 x mini-USB Type B, 1 x serial (RS-232) RJ-45, 2 x 1000Base-X SFP, 2 x alarm, 8 x 10/100/1000 Base-T RJ-45
Expansion Slots: 1 (total) / 1 (free) x SD Memory Card
Power
Device Type: Internal power supply
Power Consumption Operational: 39 watt
Redundant Power Supply: Yes
Electric Current Required: 5.4 A
Memory and Processor
RAM Installed: 4 GB
Flash Memory Installed: 1.5 GB
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 185 degree Fahrenheit
Humidity Range Storage: 5 - 95% (non-condensing)
MTBF: 549,808 Hours
Physical Characteristics
Form Factor (Hubs & Switches): DIN rail mountable
Built-in Devices: SD card reader
Dimensions and Weight
Height: 6 inch
Width: 3.6 inch
Depth: 5.3 inch
Weight: 3.75 lbs
Certifications and Listing
Compliant Standards: IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Compliant Standards: AS/NZS CISPR 32 Class A, CB 60950-1, CISPR 11 class A, CISPR 35, CNS 13438 Class A, EN 300 386, EN 50121-4, EN 55032/CISPR 32 Class A, EN 60068-2-52, EN 60068-2-60, EN 60079-0, EN 60079-15, EN 61000-4-10, EN 61000-4-16, EN 61000-4-17, EN 61000-4-18, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61326-1, EN 61850-3, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-78, IEC 60079-0, IEC 60079-15, IEC 60950-1, IEC 61850-3, IEC 62368-1, IEC/EN 61010-2-201, IEEE 1588, IEEE 1613, KN32 Class A, KN35, UL 121201, UL/CSA 60079-0, UL/CSA 60079-15, UL/CSA 61010-2-201, UL/CSA/EN 62368-1, UL/CSA60950-1, VCCI Class A
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
