Product Information
Cisco's Catalyst IE-3300-8P2S-E is a rugged DIN rail switch for industrial sites, with eight Gigabit PoE+ ports and two SFP slots. It supports a 360 W PoE budget, runs on DC power from -40 to 140 F and offers Network Essentials features such as inter-VLAN routing, DHCP snooping and Flexible NetFlow.
Key Features
- 8 x 10/100/1000 RJ-45 PoE+ ports
- 2 x SFP slots
- 360 W PoE budget
- -40 to 140 F operating range
- DIN rail mount, DC power
- 3 alarm ports
Product Information
Brand: Cisco
Manufacturer: Cisco Systems
Product Line: Cisco Catalyst
Model: IE3300 Rugged Series
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: DHCP, NTP, SCP, SNMP, SNMP 3, SSH
Routing Protocol: IGMP, IGMPv2, IGMPv3
Authentication Method: RADIUS, TACACS+
Capacity: IGMP multicast groups: 1000, Queues: 8, STP instances: 128, VLAN IDs: 256
Features: BPDU Guard, Broadcast Storm Control, DHCP server, DHCP snooping, Dying Gasp support, Dynamic ARP Inspection (DAI), Flexible NetFlow (FNF), Guest VLAN, IGMP filtering, IGMP querier, IGMP snooping, Inter-VLAN Routing, IP source guard, IPv6 support, LLDP support, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, Per-VLAN Spanning Tree Plus (PVST+), Rapid Spanning Tree Protocol (RSTP) support, Rate limit, Remote Switch Port Analyzer (RSPAN), Resilient Ethernet Protocol (REP), SmartPort technology, Storm Control, Switched Port Analyzer (SPAN), Syslog support, Uni-Directional Link Detection (UDLD), Unicast Storm Control, VLAN Trunking Protocol (VTP) v.2, VLAN Trunking Protocol (VTP) v.3, Voice VLAN
Connectivity
Ports: 10
Port Quantity: 10
Port Type: 10/100/1000 (8 PoE+)
Ports (2nd) Quantity: 2
Ports Type (2nd): SFP (mini-GBIC)
Interface Provided: 1 x console mini-USB, 1 x serial (RS-232) RJ-45 console, 10 x 10/100/1000 Base-T RJ-45 8 ports (PoE+), 2 x SFP, 3 x alarm
Power Over Ethernet (PoE): PoE+
Power
Device Type: Internal power supply
Power Consumption Operational: 35 watt
PoE Budget: 360 watt
Memory and Processor
RAM Installed: 2 GB
Flash Memory Installed: 1.5 GB
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 185 degree Fahrenheit
MTBF: 611,350 Hours
Physical Characteristics
Form Factor (Hubs & Switches): DIN rail mountable
Built-in Devices: SD card reader
Dimensions and Weight
Height: 6 inch
Width: 3.6 inch
Depth: 5.3 inch
Weight: 3.75 lbs
Certifications and Listing
Compliant Standards: AS/NZS CISPR 32 Class A, CISPR 11 class A, CISPR 35, CNS 13438 Class A, EN 300 386, EN 50121-4, EN 55032/CISPR 32 Class A, EN 60068-2-52, EN 60068-2-60, EN 60079-0, EN 60079-15, EN 61000-4-10, EN 61000-4-16, EN 61000-4-17, EN 61000-4-18, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61326-1, EN 61850-3, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-78, IEC 60079-0, IEC 60079-15, IEC 60950-1, IEC 61850-3, IEC 62368-1, IEC/EN 61010-2-201, IEEE 1588, IEEE 1613, IP30, KN32 Class A, KN35, MIL-STD-810, UL 121201, UL 62368-1, UL/CSA 60079-0, UL/CSA 60079-15, UL/CSA 61010-2-201, UL/CSA60950-1, VCCI Class A
Compliant Standards: IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Warranty
Limited Warranty: 5 Year
Service & Support Details: Limited warranty - 5 years
