Product Information
The Cisco Meraki MX75 is a cloud managed desktop security and SD-WAN appliance listed at 1 Gbps for stateful firewall, NGFW and site to site VPN, for up to 200 users and 75 VPN tunnels. It has two Gigabit RJ-45 WAN ports and one SFP WAN, eight Gigabit LAN ports plus two PoE+ ports, and USB 3.0, and draws about 12 W.
Key Features
- 1 Gbps firewall / NGFW / VPN
- Up to 200 users, 75 tunnels
- 2 x RJ-45 + 1 x SFP WAN
- 8 x LAN + 2 x PoE+
- USB 3.0
- Cloud managed
Product Information
Brand: Cisco Meraki
Manufacturer: Meraki
Product Line: Cisco Meraki
Model: MX75
Product Type: Security appliance
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: DHCP, IPSec, L2TP, PPPoE
Routing Protocol: MPLS, Static IP routing
Capacity: Concurrent VPN tunnels: 75, Maximum number of users: 200
Network Device: Next-generation firewall performance: 1 Gbps, Stateful firewall throughput: 1 Gbps, VPN throughput (site to site): 1 Gbps
Features: 3G/4G USB Dongle Support, 802.1x authentication, Content filtering, DHCP support, DMZ support, Firewall protection, Firmware upgradable, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), IP Security (IPSec) support, IPSec Virtual Private Network (VPN), Layer 7 switching, Link Aggregation, Load balancing, MPLS VPN, NAT support, Quality of Service (QoS), Static routing, Traffic shaping, VLAN support, VPN client, Wall mountable
Connectivity
Ports: 10
Interface Provided: 1 x 1000Base-T - SFP (WAN), 1 x USB 3.0 - Type A, 2 x 1000Base-T - RJ-45 (WAN), 2 x 1000Base-T (PoE+) - RJ-45, 8 x 1000Base-T - RJ-45
Power Over Ethernet (PoE): PoE+
Power
Device Type: External power adapter
Power Consumption Operational: 12 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Dimensions and Weight
Height: 1.1 inch
Width: 11.1 inch
Depth: 5.8 inch
Weight: 29.98 ounce
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
