Product Information
The Cisco Secure Firewall 1230 is a desktop firewall running Cisco Threat Defense, listed at 13 Gbps firewall with AVC and 9 Gbps with AVC and IPS, up to 400,000 sessions and 500 VPN peers. It has eight Gigabit RJ-45 ports, four 1/10G SFP+ ports, management and console ports, USB and a 960 GB drive. The description quotes 18 Gbps firewall, so figures differ by test type.
Key Features
- 13 Gbps FW + AVC (listed)
- 9 Gbps FW + AVC + IPS
- 8 x 1G RJ-45
- 4 x 1/10G SFP+
- 960 GB storage
- Desktop, Threat Defense
Product Information
Brand: Cisco
Manufacturer: Cisco Systems
Product Line: Cisco Secure Firewall
Model: 1230
Product Type: Security appliance
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate: 1 GBps
Capacity: Maximum concurrent sessions with AVC: 400000, Maximum VPN peers: 500, New connections per second with AVC: 50000, VRF instances: 10
Network Device: Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (1024B): 9 Gbps, Firewall and Application Visibility and Control (AVC) throughput (1024B): 13 Gbps, IPSec VPN throughput (1024B TCP w/Fastpath): 13 Gbps, NGIPS throughput (1024B): 11 Gbps, Stateful inspection firewall throughput: 18 Gbps, TLS hardware decryption: 2.5 Gbps
Features: 1 fan, Auto duplex mode, Auto-uplink (auto MDI/MDI-X), High Availability, Reset button
Software Type: Cisco Threat Defense 7.7
Connectivity
Interface Provided: 1 x management - RJ-45, 1 x serial / console - RJ-45, 1 x USB - Type C, 1 x USB 3.0 - Type A, 4 x 1000Base-X/10GBase-X - SFP+, 8 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Consumption Operational: 32 watt
Memory and Processor
Hard Drive Capacity: 960 GB
Port Expansion Hard Drive Type: SSD
Drive Interface: PCI Express (NVMe) / U.2
Physical Characteristics
Form Factor: Desktop
Airflow Direction: Front to back airflow
Status Indicators: Alarm, Link/activity/speed, Management, Power, SFP, SSD activity, System
Installed Quantity: 1
Dimensions and Weight
Height: 1.7 inch
Width: 11.2 inch
Depth: 17.2 inch
Weight: 9.35 lbs
Included Items
Cables: 1 x console cable - 6 ft
Certifications and Listing
Compliant Standards: AS/NZS 60950-1, AS/NZS 62368-1, AS/NZS CISPR22 Class A, CAN/CSA-C22.2 No. 60950-1, CAN/CSA-C22.2 No. 62368-1, CISPR 22 Class A, CISPR 24, CNS 13438 Class A, EN 300386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 62368-1, EN55024, EN61000-3-3, FCC CFR 47 Part 15 Class A, ICES-003 Class A, IEC 60950-1, IEC 62368-1, KN22 Class A, KN24, TCVN 7189, TVCN 7317, UL 60950-1, UL 62368-1, VCCI Class A
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
