Product Information
Built for indoor optical connections where low loss and a compact breakout matter, this CommScope SYSTIMAX ULL cable splits one MPO-8/APC single mode feed into eight LC/UPC single mode connectors. You get multi-fiber distribution in tight spaces while keeping Ultra Low Loss performance.
The plenum-rated, stranded design uses G.657.A2 single mode fiber (TeraSPEED) with a 12 inch breakout and polarity method B enhanced, so it installs in building air spaces and tight routing paths. It meets several regional and quality standards, including ANATEL, RoHS, China RoHS, UK RoHS and ISO 9001:2015, and is rated for operation from 14°F to 140°F.
Specifications:
Brand: SYSTIMAX
Manufacturer part number: UQGQPLUF8-JDF010
Product line: SYSTIMAX ULL
Cable type: Network cable
Fiber mode: Singlemode
Fiber count: 8
Connector, end A: 1 x MPO-8/APC single mode (male)
Connector, end B: 8 x LC/UPC single mode (male)
Features: Indoor, Plenum, Stranded, 12" breakout, No gland, No pulling grip, Polarity Method B Enhanced, TeraSPEED fiber type, Ultra Low Loss (ULL)
Length: 3.05 m (10 ft)
Color: Yellow
Operating temperature: 14°F to 140°F
Quantity in package: 1
Standards and compliance: G.657.A2, ANATEL, China RoHS, ISO 9001:2015, RoHS, UK RoHS
