Product Information
This Cradlepoint R2105 package pairs the ruggedized 5G in-vehicle router with a 3 year NetCloud Mobile Performance Essentials + Advanced Plan. It uses four internal antennas, dual band Wi-Fi 6, a 2.5GbE LAN port and PoE Class 4, and handles up to 100 typical clients with 900 Mbps firewall throughput.
Key Features
- 3 years NetCloud Mobile Performance Essentials + Advanced
- 5G NR and LTE Advanced Pro, 2 x Nano SIM
- Wi-Fi 6 dual band, 4 internal antennas
- 1 x 2.5GbE LAN, PoE Class 4
- 900 Mbps firewall, 300 Mbps VPN, 100 typical clients
- Accessory kit, GPIO and network cables included
Product Information
Product Type #2: Wireless cellular modem
Brand: CradlePoint
Manufacturer: CradlePoint
Product Line: Cradlepoint R2100 Series
Model: R2105
Product Type: Wireless router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Color Category: Black
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: 2.5 Gigabit Ethernet, 802.11ax, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Bridge & Router: IPS throughput: 650 Mbps, Stateful firewall throughput: 900 Mbps, VPN throughput (IPSec): 300 Mbps
Modem Transmission Data Rate: 4.14 GBps
Line Coding Format: 256 QAM
Capacity: Concurrent TCP sessions: 32000, Concurrent VPN tunnels: 10, Typical client count: 100
Wireless LAN: 802.11a/b/g/n/ac/ax
Broadband Transmission Technology: 2.4 GHz / 5 GHz
Cellular Data Connectivity Technology: 5G NR, HSPA+, LTE Advanced Pro, UMTS, WCDMA
Antennas: 4
Antenna Form Factor: Internal
Features: 2x2 MU-MIMO technology, DFS support, Dual band, Ignition Sense, Passive GNSS, PoE Class 4, Short Message Service (SMS)
Bundled Services: 3 years NetCloud Mobile Performance Essentials + Advanced Plan
Connectivity
Interface Provided: LAN: 1 x 2.5GBase-T - RJ-45
Expansion Slots: 2 (total) / 2 (free) x Nano-SIM
Technical Information
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 5 - 95%
Physical Characteristics
Form Factor (Hubs & Switches): In-vehicle
Status Indicators: Status
Dimensions and Weight
Height: 3.2 inch
Width: 4.5 inch
Depth: 15.2 inch
Weight: 3.22 lbs
Included Items
Included Accessories: Accessory kit, Mounting template
Cables: 1 x GPIO cable - 10 ft, Network cable - 5.5 ft
Certifications and Listing
Compliant Standards: IEEE 802.3at
Warranty
Service Activation: No
