Product Information
The Cradlepoint R2400 is a rugged, modular 5G router with Wi-Fi 7 for in-vehicle, desktop, rack or surface mounting. Quick specs list a 1 year NetCloud Mobile Performance Essentials Plan and T-Mobile, AT&T and Verizon Wireless. It has four 2.5GbE and two Gigabit ports, 2 Gbps firewall throughput and FIPS 140-3; the power adapter is not included.
Key Features
- 1 year NetCloud Mobile Performance Essentials per quick specs
- 5G FR1 and LTE Cat 20, 2 x Nano SIM, eSIM
- Wi-Fi 7, up to 5765 Mbps on 5 GHz
- 4 x 2.5GbE, 2 x GbE, USB-C, GPIO
- 2 Gbps firewall, 800 Mbps VPN, FIPS 140-3
- Power adapter not included
Product Information
Product Type #2: Wireless cellular modem
Brand: Ericsson
Manufacturer: CradlePoint
Product Line: Ericsson Cradlepoint
Model: R2400
Product Type: Wireless router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Color Category: Black
Country: North America
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: 2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n
Network Standard: IPSec
Bridge & Router: Maximum data rate (2.4 GHz): 1376 Mbps, Maximum data rate (5 GHz): 5765 Mbps, Stateful firewall throughput: 2 Gbps, VPN throughput (IPSec): 800 Mbps
Encryption: FIPS 140-3, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Line Coding Format: 256 QAM
Capacity: Concurrent VPN tunnels: 20
Wireless LAN: 802.11a/b/g/n/ac/ax/be
Broadband Transmission Technology: 2.4 GHz / 5 GHz
Cellular Data Connectivity Technology: 5G FR1, 5G NR, FDD LTE, LTE Advanced Pro Cat 20, TDD LTE
IoT Communications Technology: LTE Cat 20
Internet of Things (IoT) Compatible: Yes
Antennas: 9
Antenna Form Factor: External detachable
Key Features: Firewall, USB port, VPN support
Features: 2x2 MIMO technology, 4x4 MIMO technology, eSIM support, GPS/GLONASS/Galileo/BeiDou support, Ignition Sense, LED status indicators, Modular design, Reset button, Reverse polarity protection, Rugged, SD-WAN support, Secure Access Service Edge (SASE), Transient voltage protection, Zero Trust Security (ZTS)
Connectivity
Interface Provided: Antenna: 1 x SMA - GNSS antenna, Antenna: 4 x RP-SMA - Wi-Fi, Antenna: 4 x SMA - 5G, Peripheral: 1 x GPIO, USB 2.0: 1 x 24 pin USB-C, WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45, WAN / LAN: 4 x 2.5GBase-T - RJ-45
Expansion Slots: 2 (total) / 2 (free) x Nano-SIM
WAN Ports Quantity: 1
Power
Device Type: External power adapter (not included)
Memory and Processor
Processor Type: ARM8
RAM Installed: 3.8 GB
Flash Memory Installed: 8 GB
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 5 - 95%
MTBF: 727,511 Hours
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, In-vehicle, Rack-mountable, Surface-mountable
Status Indicators: NCM, Power, Signal strength, WAN
Built-in Devices: 5G modem, GPS / GLONASS / Galileo / Beidou, LED panel
Dimensions and Weight
Height: 1.7 inch
Width: 8.8 inch
Depth: 7.7 inch
Weight: 3.62 lbs
Included Items
Cables: 1 x GPIO / power cable - 10 ft
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v
Warranty
Service Activation: No
