Product Information
This listing is titled Cradlepoint R980, but the spec data shows model S400 with Wi-Fi 5, LTE Cat 6, two PoE Gigabit ports and 95 Mbps firewall throughput, and quick specs mention a 3 year NetCloud IoT Essentials Plan. Because the title and specs disagree, please contact us to confirm the exact model and plan before ordering. The listing is marked TAA compliant.
Key Features
- Title R980, spec model S400, please confirm
- 5G NR and LTE listed, 2 x Nano SIM, eSIM
- Wi-Fi 5 dual band
- 2 x GbE PoE WAN/LAN, USB 2.0, expansion slot
- GNSS receiver, Kensington slot
- TAA compliant per title and quick specs
Product Information
Product Type #2: Wireless cellular modem
Brand: Ericsson
Manufacturer: CradlePoint
Product Line: Ericsson Cradlepoint
Model: S400
Product Type: Wireless router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Color Category: Black
Country: Global
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Bridge & Router: Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1.2 Gbps, Stateful firewall throughput: 95 Mbps, VPN throughput (IPSec): 20 Mbps
Encryption: WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Modem Transmission Data Rate: 150 MBps
Line Coding Format: 16 QAM
Capacity: Concurrent TCP sessions: 32000, Concurrent VPN tunnels: 20, Layer 2 VLANs: up to 64, Typical client count: 50
Wireless LAN: 802.11a/b/g/n/ac
Broadband Transmission Technology: 2.4 GHz / 5 GHz
Cellular Data Connectivity Technology: 5G NR, FDD LTE, TDD LTE
IoT Communications Technology: 5G, LTE Cat 6
Internet of Things (IoT) Compatible: Yes
Antennas: 3
Antenna Form Factor: External detachable
Key Features: Firewall, USB port, VPN support
Features: 2x2 MIMO technology, 3GPP Release 11, eSIM support, GPS/GLONASS/Galileo/BeiDou support, Plastic housing, Reset button, Security slot (Kensington security lock compatible)
Connectivity
Interface Provided: Antenna: 1 x RP-SMA - Wi-Fi, Antenna: 2 x SMA - LTE, USB 2.0: 1 x 4 pin USB Type A, WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45
Expansion Slots: 1 expansion slot, 2 (total) / 2 (free) x Nano-SIM
WAN Ports Quantity: 1
Power
Device Type: External power adapter
Memory and Processor
Processor Brand: ARM
Technical Information
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 10 - 90%
MTBF: 1,407,191 Hours
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Built-in Devices: GNSS receiver, GPS / GLONASS / Galileo
Dimensions and Weight
Height: 1.6 inch
Width: 5.3 inch
Depth: 4.8 inch
Weight: 21.2 ounce
Included Items
Included Accessories: Antennas, Power supply
Certifications and Listing
Compliant Standards: IEEE 802.11k, IEEE 802.11v, Wi-Fi CERTIFIED
Warranty
Service Activation: No
