Product Information
The Cradlepoint W1855-5GC is an outdoor 5G wideband adapter for fixed sites, mounted on a pole or wall. It connects over two 2.5GbE ports, one with PoE+, reaches up to 2 Gbps and is powered by a PoE injector. This SKU includes a 1 year NetCloud Branch 5G Adapter Essentials Plan and Advanced Plan.
Key Features
- 1 year NetCloud Branch 5G Adapter Essentials and Advanced
- 5G NR and LTE, 3GPP Release 16, 4x4 MIMO
- 2 x 2.5GBase-T WAN/LAN, one PoE+
- Up to 2 Gbps throughput, SD-WAN support
- 2 x Nano SIM, passive GNSS
- Pole/wall mount kit, 4 N connector antennas included
Product Information
Product Type #2: Wireless cellular modem
Brand: CradlePoint
Manufacturer: CradlePoint
Product Line: Cradlepoint W-Series 5G Wideband Adapter
Model: W1855-5GC
Product Type: Router
Product Type: Wireless cellular modem
Device Type: Power injector
Packaged Quantity: 1
Color Category: White
Country: North America (US and Canada)
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 2.5 Gigabit Ethernet
Bridge & Router: Captive modem mode throughput: 2 Gbps, IP pass-through mode throughput: 2 Gbps, Standard NAT mode throughput: 2 Gbps
Modem Transmission Data Rate: 3.4 GBps
Line Coding Format: 256 QAM
Cellular Data Connectivity Technology: 5G NR, HSPA+, LTE, WCDMA
Antennas: 4
Antenna Form Factor: External detachable
Features: 3GPP Release 16, 4x4 MIMO technology, Cloud managed, Passive GNSS, SD-WAN support, SMS remote control
Bundled Services: 1 year NetCloud Branch 5G Adapter Essentials Plan and Advanced Plan
Connectivity
Interface Provided: Antenna: 4 x N connector, WAN / LAN: 1 x 2.5GBase-T - RJ-45, WAN / LAN: 1 x 2.5GBase-T (PoE+) - RJ-45
Expansion Slots: 2 (total) / 2 (free) x Nano-SIM
Technical Information
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 10 - 90%
MTBF: 376,671 Hours
Physical Characteristics
Form Factor (Hubs & Switches): Pole-mountable, Wall-mountable
Mounting Kit: Included
Dimensions and Weight
Height: 2.2 inch
Width: 8 inch
Depth: 6.5 inch
Weight: 2.87 lbs
Included Items
Included Accessories: 4 x cellular antennas, Pole/wall mount kit, RJ45 dust cover set
Certifications and Listing
Compliant Standards: IEEE 802.3at
Warranty
Service Activation: No
