Product Information
CyberData's 011236 is a small 3-port Gigabit switch that turns one network drop into two Gigabit connections, for a PC or point of sale station. It takes its power from a USB port, so no separate power supply is needed.
Key Features
- 3 x 10/100/1000 RJ-45 ports
- Powered by USB Type B
- VLAN, QoS, MAC filtering
- Desktop design
Product Information
Brand: CyberData
Manufacturer: CYBER DIM
Product Line: CyberData
Model: 3-Port Gigabit Ethernet Switch
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Network and Communication
Switching Type: Gigabit Ethernet
MAC Address Table Size: 1K entries
Jumbo Frame Support: 9216 bytes
Features: Auto-negotiation, Auto-sensing per device, Auto-uplink (auto MDI/MDI-X), MAC address filtering, Quality of Service (QoS), USB powered, VLAN support
Connectivity
Ports: 3
Port Quantity: 3
Port Type: 10/100/1000
Interface Provided: 1 x USB Type B, 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Power
Electric Current Required: 350 mA (operating)
Technical Information
Min Operating Temperature: 14 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Status Indicators: Link/activity, Port transmission speed, Status
Dimensions and Weight
Height: 1.1 inch
Width: 3.8 inch
Depth: 2.8 inch
Weight: 3.21 ounce
Included Items
Cables: 1 x USB cable
Certifications and Listing
Compliant Standards: RoHS
Compliant Standards: IEEE 802.3u
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
Service Activation: No
