Product Information
The D-Link DGS-1100-16V2 is a 16-port Gigabit smart managed switch with a fanless design. It covers VLANs, QoS, IGMP snooping, port mirroring, loop detection, cable diagnostics and storm control, and its 32 Gbps switching capacity keeps all ports at line rate. It sits on a desk or mounts in a 1U rack with the included brackets.
Key Features
- 16 x 10/100/1000 RJ-45 ports
- Smart managed: VLAN, QoS, IGMP snooping, port mirroring
- Cable diagnostics, loop detection, storm control
- 32 Gbps switching capacity
- Fanless, 10.1 W
- Desktop or 1U rack mount, brackets included
Product Information
Brand: D-Link
Manufacturer: D-Link
Product Line: D-Link DGS
Model: 1100-16V2
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: ICMP, SNMP 2
Routing Protocol: IGMP, IGMPv2, IGMPv3
Encryption: SSL
Performance: Forwarding performance: 23.81 Mpps, Switching capacity: 32 Gbps
Capacity: IGMP groups: 128, VLAN groups: 128, VLAN IDs: 4094
MAC Address Table Size: 8K entries
Jumbo Frame Support: 10240 bytes
Features: 512KB packet buffer, ARP support, Asymmetric VLAN, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Bandwidth control, BOOTP support, Broadcast Storm Control, Cable Diagnostics Function, DHCP client, DiffServ Code Point (DSCP) support, DNA support, DoS attack prevention, Energy-Efficient Ethernet (EEE), Fanless, Flow control, Full duplex mode, Head-of-line (HOL) Blocking Prevention, IGMP querier, IGMP snooping, LLDP support, Loopback detection, Multicast Storm Control, Port mirroring, Port Security, Port-based QoS, Port-based VLAN, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Spanning Tree Protocol (STP) support, Tagged VLAN, Unicast Storm Control, Unknown Storm Control, VLAN group, VLAN management, VLAN support, Voice VLAN, Weighted Round Robin (WRR)
Smart: Yes
Connectivity
Ports: 16
Port Quantity: 16
Port Type: 10/100/1000
Interface Provided: 24 x 1000Base-T RJ-45
Power
Device Type: Internal power supply
Frequency: 50/60 hertz
Power Consumption Operational: 10.1 watt
Memory and Processor
Clock Speed: 500 megahertz
RAM Installed: 128 megabyte
Flash Memory Installed: 16 megabyte
Technical Information
Min Operating Temperature: 23 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 0 - 95% (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 0 - 95% (non-condensing)
MTBF: 710,519 Hours
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, Rack-mountable
Height (Rack Units): 1
Status Indicators: Link/activity/speed, Power, Status
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 11 inch
Depth: 7.1 inch
Weight: 2.67 lbs
Included Items
Included Accessories: 2 x 19" mounting brackets, 4 rubber feet
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Warranty
Service Activation: No
