Product Information
D-Link's SmartPro DGS-1510-28X is a stackable managed switch with 24 Gigabit ports and four 10G SFP+ ports. It offers 128 Gbps of switching capacity, stacks up to six units and adds Layer 3 features and D-Link Green power saving.
Key Features
- 24 x 10/100/1000 RJ-45 ports
- 4 x 10G SFP+ ports
- 128 Gbps switching, 95.24 Mpps
- Stack up to 6 units
- Layer 3 features, D-Link Green
- Desktop or rack mount
Product Information
Brand: D-Link
Manufacturer: D-Link
Product Line: D-Link SmartPro
Model: DGS-1510-28X
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black, Silver
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, HTTP, RMON 1, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP
Routing Protocol: Static IPv4 routing, Static IPv6 routing
Authentication Method: RADIUS, Secure Shell v.2 (SSH2)
Encryption: PEAP, SSL, SSL 2.0, SSL 3.0, TLS, TTLS
Performance: Forwarding performance (64-byte packet size): 95.24 Mpps, Stacking bandwidth: 20 Gbps, Switching capacity: 128 Gbps
Capacity: ACL entries: 256, ACL rules: 768, ARP entries: 256, IGMP groups: 512, IPv4 routing table entries: 64, IPv6 routing table entries: 32, Layer 2 multicast addresses: 128
MAC Address Table Size: 16000 entries
Jumbo Frame Support: 9000 bytes
Stackable: Stackable
Features: Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Bandwidth control, Broadcast Storm Control, Cable Diagnostics Function, Class of Service (CoS), D-Link Green Technology, D-Link Single IP Management (SIM), Deficit Weighted Round Robin (DWRR), DHCP client, DHCP server, DHCP snooping, DiffServ Code Point (DSCP) support, DoS attack prevention, Dynamic ARP Inspection (DAI), Energy Efficient Ethernet, Flow control, Full duplex capability, Generic VLAN Registration Protocol (GVRP), IGMP snooping, IP-MAC binding, IPv6 support, LLDP support, MLD snooping, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Quality of Service (QoS), RADIUS support, Rapid Spanning Tree Protocol (RSTP) support, Safeguard Engine, SNMP trap, SNTP support, Spanning Tree Protocol (STP) support, Store and forward, Strict Priority Queuing (SPQ), Syslog support, Tagged VLAN, Unicast Storm Control, VLAN support, Weighted Round Robin (WRR) queuing
Max Units In A Stack: 6
Connectivity
Ports: 28
Port Quantity: 24
Port Type: 10/100/1000
Ports (2nd) Quantity: 4
Ports Type (2nd): 10 Gigabit SFP+
Interface Provided: 1 x console RJ-45 management, 24 x 1000Base-T RJ-45, 4 x 10GBase-X SFP+
Power
Device Type: Internal power supply
Frequency: 50/60 hertz
Power Consumption Operational: 22.3 watt
Technical Information
Min Operating Temperature: 23 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 0 - 95% (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 0 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, Rack-mountable
Height (Rack Units): 1
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 8.3 inch
Weight: 4.41 lbs
Certifications and Listing
Compliant Standards: BSMI, C-Tick, CB, CCC, cUL, FCC, VCCI
Compliant Standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
