Product Information
The Digi Connect EZ 2 is a serial device server, not a wireless adapter, that puts two RS-232/422/485 devices on the network for automation, robotics, data acquisition and POS equipment. It has two auto sensing serial ports and two Gigabit RJ-45 ports, Digi TrustFence security with firewall, IPsec and OpenVPN, Modbus support and CLI, web, SSH and SNMP management. It has 256 MB of RAM and 4 GB of flash, draws about 4.5 W and includes a DIN rail clip.
Key Features
- Serial device server
- 2 x RS-232/422/485 ports
- 2 x Gigabit RJ-45 ports
- Firewall, IPsec, OpenVPN
- Modbus compatible
- DIN rail clip included
Product Information
Brand: Digi
Manufacturer: Digi International
Product Line: Digi Connect EZ
Model: 2
Product Type: Device server
Packaged Quantity: 1
Color Category: Black
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232, RS-422, RS-485
Network Standard: DHCP, FTP, HTTP, HTTPs, IPSec, NTP, SMTP, TCP/IP, UDP/IP
Remote Management: CLI, HTTP, HTTPS, NTP, SCP, SMTP, SNMP 2, SNMP 3, SSH, Telnet
Routing Protocol: BGP, OSPF, RIP-1, RIP-2, VRRP
Authentication Method: LDAP, RADIUS, TACACS+
Encryption: 256-bit AES, 256-bit AES-CBC, DH, IKEv1, IKEv2, MDS, RSA, SHA-1, SHA-256, SHA-384, SHA-512, TLS 1.2, Triple DES
Features: Auto-sensing per device, Digi TrustFence, DNS server, DynDNS, FTP client, GRE tunneling, IP address filtering, IPSec NAT-Traversal (NAT-T), MAC address filtering, Modbus compatible, NAT support, NTP server, OpenVPN client, OpenVPN server, Port forwarding, SNTP support, Stateful Packet Inspection Firewall (SPIF), Syslog support, VLAN support, VPN support
Connectivity
Ports: 2
Interface Provided: 2 x 1000Base-T - RJ-45, 2 x RS-232/422/485 - RJ-45
Power
Device Type: External power adapter
Power Consumption Operational: 4.5 watt
Memory and Processor
RAM Installed: 256 megabyte
Flash Memory Installed: 4 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: External
Status Indicators: LAN, Power, Serial, Signal
Dimensions and Weight
Height: 1.4 inch
Width: 7.6 inch
Depth: 5.3 inch
Included Items
Included Accessories: DIN-rail clip
Certifications and Listing
Compliant Standards: AS/NZS CISPR 32, CB, EN 62311, FCC Part 15 B, FIPS 197, ICES-003, IEC 62368-1, RED, RoHS 3
Warranty
Service Activation: No
