Product Information
Digi's Connect EZ 8 Wi-Fi (EZ08-B100-US) is a rack mount device server with eight RS-232 ports plus dual band Wi-Fi 5 that can run as an access point or client. It also has two 10G SFP+ ports, two Gigabit RJ-45 ports and two USB 3.1 ports, and includes a 1-year Digi LifeCycle Assurance. This is a serial server, not a switch.
Key Features
- 8 x RS-232 serial ports (RJ-45)
- Wi-Fi 5, 2.4/5 GHz, AP or client mode
- 2 x 10G SFP+, 2 x Gigabit RJ-45
- 2 x USB 3.1 Gen 1 Type A
- 1-year Digi LifeCycle Assurance
- Antennas, US power cable, rack ears
Product Information
Brand: Digi
Manufacturer: Digi International
Product Line: Digi Connect EZ
Model: 8 Wi-Fi
Product Type: Device server
Packaged Quantity: 1
Color Category: Black
Country: United States
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, RS-232
Remote Management: HTTP, HTTPS, NTP, SCP, SMTP, SNMP 3, SSH, Syslog, Telnet
Authentication Method: LDAP, RADIUS, TACACS+
Encryption: WPA-Enterprise, WPA2-Enterprise, WPA2-Personal, WPA3-Personal
Features: Access Point operational mode, Auto-sensing per device, Single-stream (1x1), SISO technology, Wireless Client Mode
Bundled Services: 1-year Digi LifeCycle Assurance
Connectivity
Ports: 8
Interface Provided: 1 x console - RJ-45, 2 x 10 Gigabit Ethernet - SFP+, 2 x 1000Base-T - RJ-45, 2 x antenna - SMA, 2 x USB 3.1 Gen 1 - Type A, 8 x RS-232 - RJ-45
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Memory and Processor
RAM Installed: 256 megabyte
Flash Memory Installed: 4 GB
Flash Memory Cards Supported: microSD, microSDHC, microSDXC
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Status Indicators: Console, Ethernet link/activity, Power, Serial, USB, Wi-Fi, WWAN
Dimensions and Weight
Height: 1.7 inch
Width: 10.2 inch
Depth: 6.3 inch
Included Items
Included Accessories: Antennas, Power cable (US), Rack Ears
