Product Information
The Digi IX30 is an industrial 4G LTE Advanced router for critical infrastructure, linking industrial controllers, process automation and smart grid assets at remote sites. It has two 10/100 Ethernet ports, an RS-232/422/485 serial port, four USB 2.0 ports, a 12 pin I/O terminal block and multi-constellation GNSS, and is FirstNet ready. It carries a 3 year limited warranty; the power adapter is not included.
Key Features
- LTE Advanced, 2 x Mini SIM, FirstNet ready
- 2 x 10/100 RJ-45, RS-232/422/485 DB-9
- 4 x USB 2.0, 12 pin I/O terminal block
- GPS, GLONASS, Galileo, BeiDou, QZSS
- Aluminum housing, DIN rail, 9 to 30 V DC
- 3 year limited warranty, adapter not included
Product Information
Product Type #2: Wireless cellular modem
Brand: Digi
Manufacturer: Digi International
Product Line: Digi
Model: IX30
Product Type: Router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Color Category: Black
Country: North America
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet
Network Standard: FTP, HTTP, HTTPs, NTP, SFTP, SMTP
Remote Management: CLI, HTTP, HTTPS, NTP, SCP, SFTP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Cellular Data Connectivity Technology: FDD LTE, LTE Advanced, TDD LTE, WCDMA
Antennas: 3
Antenna Form Factor: External detachable
Key Features: USB port
Features: 15KV ESD Protector, Aluminum housing, Auto-sensing per device, FirstNet ready, Flow control, Primary Responder, SMS remote control, SNTP support, Syslog support
Connectivity
Interface Provided: 1 x input / output - 12 pin terminal block, 2 x 10Base-T/100Base-TX - RJ-45, Antenna: 3 x SMA, Serial: 1 x RS-232/422/485 - 9 pin D-Sub (DB-9), USB 2.0: 4 x 4 pin USB Type A
Expansion Slots: 2 (total) / 2 (free) x Mini-SIM
Power
Device Type: External power adapter (not included)
Required Voltage: DC 9 - 30 volt
Technical Information
Min Operating Temperature: -29.2 degree Fahrenheit
Max Operating Temperature: 165.2 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): DIN rail mountable
Status Indicators: LTE, Power, Signal strength
Built-in Devices: Beidou, Galileo, GLONASS, GNSS receiver, GPS, QZSS
Dimensions and Weight
Height: 5 inch
Width: 2 inch
Depth: 3.9 inch
Weight: 17.64 ounce
Certifications and Listing
Compliant Standards: ANSI/ISA 12.12.01-2015, AS/NZS CISPR 32, ATEX II 3 G Ex nA IIC T4 Gc, CAN/CSA C22.2 No. 213-15, DEMKO 15 ATEX 1574X Rev. 1, EN 60079-0:2012+A11:2013, EN 60079-15:2010, FCC Part 15 B, ICES-003, IP30, PTCRB, RoHS 3, UL 62368-1 Second Edition, UL 62368:2014 Second Edition
Warranty
Limited Warranty: 3 Year
Service & Support Details: Limited warranty - 3 years
Service Activation: No
