Product Information
The Digi PortServer TS 2 P MEI (70001992) is a 2 port device server that connects RS-232, RS-422 or RS-485 devices to an IP network with flexible power options. It accepts 802.3af PoE (mid or end span) so one Ethernet cable carries power and data, and offers powered serial to feed attached devices. It has one 10/100 RJ-45 port, supports SSH v2, PPP, flow control and DHCP, and is managed by web (HTTP and HTTPS), Telnet and SNMP. An external power adapter is also supported.
Key Features
- 2 serial ports, MEI
- RS-232, RS-422, RS-485
- 802.3af PoE powered
- Powered serial option
- 10/100 Ethernet
- SSH v2 security
Product Information
Brand: Digi
Manufacturer: Digi International
Product Line: Digi PortServer
Model: TS 2 P MEI
Product Type: Device server
Packaged Quantity: 1
Country: Worldwide
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, PPP, RS-232, RS-422, RS-485
Network Standard: TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS, SNMP, Telnet
Authentication Method: Secure Shell v.2 (SSH2)
Operating System Required: HP-UX, IBM AIX, Linux, Microsoft Windows 2000, Microsoft Windows 98, Microsoft Windows Millennium Edition, Microsoft Windows NT, Microsoft Windows XP, SCO OpenServer, SunSoft Solaris, UnixWare
Features: ARP support, DHCP support, Flow control, Manageable, RARP support
Connectivity
Ports: 2
Interface Provided: 1 x 100Base-TX - RJ-45, 2 x serial
Power Over Ethernet (PoE): PoE
Power
Device Type: External power adapter
Memory and Processor
Optical Drive Type: None
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 5 - 90%
Physical Characteristics
Form Factor: External
Status Indicators: Link/activity, Power
Dimensions and Weight
Height: 5.2 inch
Width: 3.3 inch
Depth: 0.9 inch
Weight: 2.26 ounce
Certifications and Listing
Compliant Standards #2: CSA 22.2 No. 950, EN55022 Class A, EN55024, FCC Class A certified, FCC Part 15, UL 1950
Compliant Standards: IEEE 802.3, IEEE 802.3af
Compliant Standards: CSA 22.2 No. 950, EN55022 Class A, EN55024, FCC Class A certified, FCC Part 15, UL 1950
Warranty
Limited Warranty: 5 Year
Service & Support Details: Limited warranty - 5 years
