Product Information
The Digi TX54 single 5G edition is a mission critical router with a 5G NR sub-6 GHz modem, LTE Advanced Pro fallback, Wi-Fi 5, Bluetooth 4.2 and four Mini SIM slots. It offers a four port Gigabit switch, RS-232, USB 3.0 and multi-constellation GNSS, with ten external antenna connectors.
Key Features
- 5G NR sub-6 GHz and LTE Advanced Pro
- 4 x Mini SIM
- Wi-Fi 5 dual band, Bluetooth 4.2
- 1 x GbE WAN/LAN, 3 x GbE LAN, RS-232, USB 3.0
- GPS, GLONASS, Galileo, BeiDou
- 18 W, 10 antennas
Product Information
Product Type #2: Wireless cellular modem
Brand: Digi
Manufacturer: Digi International
Product Line: Digi
Model: TX54
Product Type: Wireless router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Color Category: Black
Country: Global
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth 4.2, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Remote Management: HTTP, HTTPS, SCP, SFTP, SNMP 2, SNMP 3, SSH
Authentication Method: RADIUS
Integrated Switch: 4-port switch
Wireless LAN: 802.11a/b/g/n/ac, Bluetooth 4.2
Broadband Transmission Technology: 2.4 GHz / 5 GHz
Cellular Data Connectivity Technology: 5G NR Sub-6 Ghz, HSPA+, LTE Advanced Pro, UMTS
Antennas: 10
Antenna Form Factor: External detachable
Key Features: USB port, VPN support
Features: 2x2 MIMO technology
Edition: Single 5G
Connectivity
Interface Provided: Antenna: 1 x - Bluetooth, Antenna: 1 x SMA - GNSS antenna, Antenna: 4 x SMA - 5G, Antenna: 4 x SMA - Wi-Fi, LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45, Serial: 1 x RS-232 - 9 pin D-Sub (DB-9), USB 3.0: 1 x 9 pin USB Type A, WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Expansion Slots: 4 (total) / 4 (free) x Mini-SIM
WAN Ports Quantity: 1
Power
Device Type: External power adapter
Power Consumption Operational: 18 watt
Memory and Processor
RAM Installed: 256 megabyte
Flash Memory Installed: 512 megabyte
Technical Information
Min Operating Temperature: -29.2 degree Fahrenheit
Max Operating Temperature: 165.2 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Status Indicators: GNSS, Power, Service, Signal, Wi-Fi, WWAN
Built-in Devices: Beidou, Galileo, GLONASS, GPS
Dimensions and Weight
Height: 2.5 inch
Width: 8.3 inch
Depth: 5.7 inch
Weight: 3.31 lbs
Certifications and Listing
Compliant Standards #2: AS/NZS CISPR 22, CB, E Mark, EN 60950, FCC Part 15 B, ICES 003, IP54, MIL-STD 810G
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Compliant Standards: AS/NZS CISPR 22, CB, E Mark, EN 60950, FCC Part 15 B, ICES 003, IP54, MIL-STD 810G
Warranty
Service Activation: No
