Product Information
The EnGenius ENH500-AX bridge kit is an outdoor 5 GHz Wi-Fi 6 bridge and access point with a 16 dBi 2x2 directional antenna, up to 1200 Mbps and point to point links up to about 5 miles. It has two Gigabit ports, IP55 sealing and 26 dBm transmit power, and includes a PoE injector and pole and wall mounting parts. This is a bridge, not a standalone antenna.
Key Features
- 5 GHz Wi-Fi 6 outdoor bridge
- 16 dBi 2x2 directional
- Up to 1200 Mbps
- Up to about 5 miles PtP
- 2 x Gigabit, IP55
- PoE injector, mounts included
Product Information
Brand: EnGenius
Manufacturer: Engenius
Product Line: EnGenius
Model: ENH500-AX
Product Type: Wireless access point
Kit: Bridge Kit
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Remote Management: MIB, SNMP 1, SNMP 2c, SNMP 3
Encryption: AES, Simultaneous Authentication of Equals (SAE), WPA2, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-Enterprise, WPA3-PSK
Line Coding Format: 1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, QPSK
Capacity: SSIDs total: 8
Wireless LAN: 802.11a/b/g/n/ac/ax
Network Band: 5 GHz
Spread Spectrum Method: OFDM, OFDMA
Network Device: Maximum throughput (5 GHz): 1200 Mbps
Antennas: 2
Antenna Form Factor: Internal
Directivity: Directional
Features: Client isolation, Hidden SSID, Linear polarization, MAC address filtering, Management Information Base (MIB), Management Information Base (MIB) II, MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-SPDU, Reset button, SSID to VLAN tagging, SU-MIMO technology, Transmit Beam-forming (TxBF) ready, VLAN management, WDS access point, WDS repeater mode, Wi-Fi Multimedia (WMM) support, Wireless SSID
Connectivity
Interface Provided: 2 x 1000Base-T - RJ-45
Power Over Ethernet (PoE): PoE
Power
Power Consumption Operational: 12.5 watt
Memory and Processor
Processor Brand: Qualcomm
Processor Type: Quad Core ARM CPU
Processor Number: Cortex-A53s
Clock Speed: 1 GHZ
Technical Information
Min Operating Temperature: -4 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Operating Humidity: 0 - 90% (non-condensing)
Ruggedized Design: Outdoor
Physical Characteristics
Form Factor: External
Status Indicators: LAN, Power, Signal, WLAN
Dimensions and Weight
Height: 3.3 inch
Width: 2.2 inch
Depth: 10.2 inch
Weight: 21.51 ounce
Included Items
Included Accessories: PoE injector, Pole mount brackets, Pole mount strap, Power cord, Product card, Wall mount screws
Certifications and Listing
Compliant Standards: IEEE 802.11e, IEEE 802.1D, IEEE 802.1Q
Compliant Standards: FCC, IP55
