Product Information
From Extreme Networks, the 4120-24MW-4Y is a stackable Layer 3 switch with 24 multi-gigabit PoE ports up to 2.5G, four 1/10/25G SFP28 ports and two 100G QSFP28 uplink or stacking ports. It lists a 680 W PoE budget and 720 Gbps of bandwidth.
Key Features
- 24 x 10M/100M/1G/2.5G RJ-45 PoE ports
- 4 x 1/10/25G SFP28 ports
- 2 x 100G QSFP28 uplink/stack ports
- 680 W PoE budget
- 720 Gbps, 535.7 Mpps, stack up to 8
- Base software license
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks 4000 series
Model: 4120-24MW-4Y
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Advanced Switching: Layer 3
Switching Type: 2.5 Gigabit Ethernet
Manageable: Yes
Remote Management: DHCP
Routing Protocol: IGMP, IGMPv2, IGMPv3, MLD, MLDv2, Policy-based routing (PBR)
Performance: Aggregate bandwidth: 720 Gbps, Frame rate: 535.7 Mpps
Capacity: ACL entries (egress): 256, ACL entries (ingress): 1024, ARP table (IPv4): 400, IP multicast entries: 150, IPv4 routes: 64, IPv6 neighbor table entries: 200, IPv6 routes: 32, Maximum number of VLANs: 4094, Policy profiles: 63, Unique permit/deny rules per switch (ACL): 440, Unique permit/deny rules per switch (traditional): 184
MAC Address Table Size: 16000 entries
Features: Jumbo Frames support, MAC and IP-based ACLs support, PVST+, sFlow
Max Units In A Stack: 8
Software Type: Base Software License
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 10/100/1000/2.5G (PoE+)
Ports (2nd) Quantity: 4
Ports Type (2nd): 1/10/25 Gigabit SFP28
Ports (3rd) Quantity: 2
Interface Provided: 1 x 10/100/1000 Base-T RJ-45 management, 1 x console (micro-USB), 1 x serial (console) RJ-45, 2 x 100GBase-X QSFP28 unpopulated, 2 x USB Type A, 24 x 10/100/1000/2.5G RJ-45 90 W, 4 x 1/10/25GBase-X SFP28 unpopulated
Power Over Ethernet (PoE): PoE
QSFP Slots: 100 Gigabit QSFP28
Power
Device Type: Internal power supply
Required Voltage: AC 200-240 volt
Power Provided: 860 watt
PoE Budget: 680 watt
Power Supplies Supported: 2
Redundant Power Supply: Optional
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 10 - 95% RH (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 10 - 95% RH (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Dimensions and Weight
Height: 1.7 inch
Depth: 17.4 inch
Weight: 11.95 lbs
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP)
Compliant Standards: ACMA RCM, ANATEL, AS/NZS 60950-1, ASTM D3580, BSMI, CAN/CSA C22.2 No. 60950-1 Second Edition 2014, China RoHS II (GB/T 26572-2011), CISPR 32, CQC, Directive 1907/2006/EU, EAC, EMC 2014/30/EU, EN 300 386, EN 55032 Class A, EN 55035, EN 60825-1, EN 61000-3-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 62368-1, EN/ETSI 300 019-2-1 v2.1.2, EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e, EN/ETSI 300 753 (1997-10), EN61000-3-3, FCC CFR 47 Part 15 Class A, FDA 21CFR1040.10, ICES-003 Class A, IEC 60950-1, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 62368-1, IEC/EN 61000-4-11, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3bt, IEEE 802.3by, KCC, LVD 2014/35/EU, NOM, NRCS, RoHS 2011/65/EU, Taiwan RoHS CNS 15663 (2013.7), TEC, UL 60950-1, UL/CUL 62368-1, VCCI Class A, WEEE 2012/19/EU
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
