Product Information
Extreme Networks' 4220-24P-4X is a stackable access switch with 24 Gigabit PoE+ ports at up to 30 W each and four 1/10G SFP+ ports for uplink or stacking. It shares a 195 W PoE budget, offers 128 Gbps of switching bandwidth and supports cloud management.
Key Features
- 24 x 10/100/1000 RJ-45 PoE+ ports, 30 W
- 4 x 1/10G SFP+ uplink/stacking ports
- 195 W PoE budget
- 128 Gbps switching, 95.2 Mpps
- Stack up to 8 units
- 1 hot-plug power supply installed
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks 4000 series
Model: 4220-24P-4X
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: DHCP
Routing Protocol: IGMP, IGMPv2, IGMPv3, MLD, MSTP, Policy-based routing (PBR), RSTP, Static IP routing, STP
Authentication Method: RADIUS
Performance: Forwarding rate: 95.2 Mpps, Stacking bandwidth: 40 Gbps, Switching bandwidth: 128 Gbps
Jumbo Frame Support: Yes
Stackable: Stackable
Features: 802.1x authentication, Access Control List (ACL) support, Cloud managed, DHCP client, DHCP relay, DHCP server, IGMP snooping, Jumbo Frames support, Link Aggregation Group (LAG), LLDP support, Media Endpoint Discovery (LLDP-MED), Multiple VLAN Registration Protocol (MVRP), Non-blocking architecture, Port Security, PVST+, Quiet mode (fan off), sFlow, Universal Zero Trust Network Access (UZTNA), VLAN support, Zero-touch provisioning (ZTP)
Max Units In A Stack: 8
Software Type: Base Software License
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 10/100/1000Base-T (PoE+)
Ports (2nd) Quantity: 4
Ports Type (2nd): 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking)
Interface Provided: 1 x management (Gigabit LAN) RJ-45, 1 x micro-USB Type B console, 1 x serial (console) RJ-45, 1 x USB Type A, 24 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W, 4 x 1/10GBase-X SFP+ uplink/stacking
Power Over Ethernet (PoE): PoE+
Power
Device Type: Internal power supply
Power Provided: 550 watt
PoE Budget: 195 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 10 - 95% RH (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 10 - 95% RH (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 13 inch
Weight: 9.63 lbs
Certifications and Listing
Compliant Standards: 2014/30/EU, 2014/35/EU, ACMA RCM, ANATEL, AS/NZS 60950-1, AS/NZS CISPR 32, ASTM D3580, BSMI, CAN/CSA C22.2 No. 60950-1 Second Edition 2014, CDRH, China RoHS II (GB/T 26572-2011), CISPR 32 Class A, CQC, EAC, EMC, EN 300 386, EN 55032 Class A, EN 55035, EN 60825-1 Class 1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 62368-1, EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2, EN/ETSI 300 019-2-2 v2.3.1 - Class 2.3, EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e, EN/ETSI 300 753 (1997-10), FCC CFR 47 Part 15 Class A, FCC CFR21 Part 1040.10, ICES-003 Class A, IEC 60950-1, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 62368-1, KCC, NOM, NRCS, REACH 1907/2006/CE, ROHS Directive 2011/65/EU, Taiwan RoHS CNS 15663 (2013.7), TEC, UL 60950-1, UL/CUL 62368-1, VCCI Class A, WEEE 2012/19/EU
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3by, IEEE 802.3bz
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
