Product Information
Extreme Networks' ExtremeSwitching 5420F-24P-4XE is a stackable Layer 3 edge switch with 24 Gigabit PoE ports at up to 30 W, four 1/10G SFP+ uplinks and two SFP-DD stacking ports. It has a 380 W PoE budget and 208 Gbps of switching capacity, with one power supply installed.
Key Features
- 24 x 10/100/1000 RJ-45 PoE ports, 30 W
- 4 x 1/10G SFP+ uplinks
- 2 x SFP-DD stacking ports
- 380 W PoE budget
- 208 Gbps switching, 154.8 Mpps
- 1 power supply installed, redundant optional
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks
Model: 5420F
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Performance: Forwarding rate: 154.8 Mpps, Switching capacity: 208 Gbps
Capacity: ACL entries (egress): 1024, ACL entries (egress): 336, ACL entries (ingress): 1024, ACL entries (ingress): 8000, ARP table (IPv4): 16000, ARP table (IPv4): 8000, ARP table (IPv6): 5750, ARP table (IPv6): 6000, IP interfaces: 1533, IP interfaces: 248, IP multicast entries: 4000, IP multicast entries: 6000, IPv4 routes: 11750, IPv4 routes: 12000, IPv6 neighbor table entries: 6000, IPv6 neighbor table entries: 8000, Maximum number of VLANs: 4059, Maximum number of VLANs: 4094, Policy profiles: 63, Unique permit/deny rules per switch: 4024
Stackable: Stackable
Features: Fan module, Mode button
Software Type: Base Software License
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 10/100/1000
Ports (2nd) Quantity: 4
Ports Type (2nd): 1 Gigabit / 10 Gigabit SFP+ (uplink)
Interface Provided: 1 x 10/100/1000 Base-T RJ-45 out-of-band network management, 1 x console (micro-USB), 1 x management (Gigabit LAN) RJ-45, 2 x network stack device SFP-DD unpopulated, 2 x USB Type A management, 24 x 1000Base-T RJ-45 30 W, 4 x 10GBase-X SFP+ uplink
Power Over Ethernet (PoE): PoE
Power
Device Type: Internal power supply
Power Provided: 660 watt
PoE Budget: 380 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Optional
Voltage Required AC/DC: AC
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 11.3 inch
Weight: 10.14 lbs
Certifications and Listing
Compliant Standards: IEEE 802.3at, IEEE 802.3bt
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Lifetime Limited
Service & Support Details: Limited warranty - lifetime
