Product Information
Extreme Networks' ExtremeSwitching 5420F-24S-4XE is a stackable Layer 3 fiber edge switch with 24 100/1000 SFP ports, four 1/10G SFP+ uplinks and two SFP-DD stacking ports. It offers 208 Gbps and MACsec, with one power supply installed and a 1 year ExtremeCloud IQ Pilot license.
Key Features
- 24 x 100/1000 SFP ports
- 4 x 1/10G SFP+ uplinks
- 2 x SFP-DD stacking ports, stack up to 8
- 208 Gbps, 154.8 Mpps, MACsec
- 1 power supply installed, redundant optional
- 1 year ExtremeCloud IQ Pilot
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks ExtremeSwitching
Model: 5420F
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Blue
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: CLI
Encryption: 128-bit AES, 256-bit AES
Performance: Aggregate bandwidth: 208 Gbps, Frame rate: 154.8 Mpps
MAC Address Table Size: 64K entries
Features: Auto-sensing per device, Full duplex mode, Half duplex mode, MACsec support
Max Units In A Stack: 8
Software Type: Base Software License, ExtremeCloud IQ Pilot (1 year)
Connectivity
Ports: 24
Port Quantity: 24
Port Type: Gigabit SFP
Ports (2nd) Quantity: 4
Ports Type (2nd): 1 Gigabit / 10 Gigabit SFP+
Ports (3rd) Quantity: 2
Interface Provided: 1 x console (micro-USB), 1 x management (Gigabit LAN) RJ-45, 1 x serial (console) RJ-45, 2 x network stack device SFP-DD, 2 x USB, 24 x 100 / 1000Base-X SFP, 4 x 1/10GBase-X SFP+
QSFP Slots: SFP-DD (stackable)
Power
Device Type: Internal power supply
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Optional
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 11.3 inch
Weight: 9.08 lbs
Certifications and Listing
Compliant Standards: IEEE 802.1ae
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
