Product Information
Extreme Networks' ExtremeSwitching 5420F-48T-4XE is a stackable Layer 3 edge switch with 48 Gigabit RJ-45 ports, four 1/10G SFP+ uplinks and two SFP-DD stacking ports. It offers 256 Gbps of switching capacity, with one AC power supply installed and a second optional.
Key Features
- 48 x 10/100/1000 RJ-45 ports
- 4 x 1/10G SFP+ uplinks
- 2 x SFP-DD stacking ports, stack up to 8
- 256 Gbps switching, 190.5 Mpps
- 1 power supply installed, redundant optional
- Base software license
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks
Model: 5420F
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Performance: Forwarding rate: 190.5 Mpps, Switching capacity: 256 Gbps
Capacity: ACL entries (egress): 1024, ACL entries (egress): 336, ACL entries (ingress): 1024, ACL entries (ingress): 8000, ARP table (IPv4): 16000, ARP table (IPv4): 8000, ARP table (IPv6): 5750, ARP table (IPv6): 6000, IP interfaces: 1533, IP interfaces: 248, IP multicast entries: 4000, IP multicast entries: 6000, IPv4 routes: 11750, IPv4 routes: 12000, IPv6 neighbor table entries: 6000, IPv6 neighbor table entries: 8000, Maximum number of VLANs: 4059, Maximum number of VLANs: 4094, Policy profiles: 63, Unique permit/deny rules per switch: 4024
MAC Address Table Size: 32K entries
Stackable: Stackable
Features: Fan module, Mode button
Max Units In A Stack: 8
Software Type: Base Software License
Connectivity
Ports: 48
Port Quantity: 48
Port Type: 10/100/1000Base-T
Ports (2nd) Quantity: 4
Ports Type (2nd): 1 Gigabit / 10 Gigabit SFP+ (uplink)
Interface Provided: 1 x 10/100/1000 Base-T RJ-45 out-of-band network management, 1 x console (micro-USB), 1 x console RJ-45, 2 x network stack device SFP-DD unpopulated, 2 x USB Type A management, 4 x 1/10GBase-X SFP+ uplink, 48 x 1000Base-T RJ-45
Power
Device Type: Internal power supply
Power Provided: 120 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Optional
Voltage Required AC/DC: AC
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 11.3 inch
Weight: 10.23 lbs
Certifications and Listing
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
