Product Information
The Extreme Networks 5720-24MW is a stackable switch with 24 multigigabit RJ-45 ports at 1/2.5/5G delivering PoE++ up to 90 W, plus two 100G QSFP28 stacking ports. It offers 1,040 Gbps of switching bandwidth with MACsec and cloud management. Power supplies are listed as not installed, so order them separately.
Key Features
- 24 x 1/2.5/5G RJ-45 PoE++ ports, up to 90 W
- 2 x 100G QSFP28 stacking ports
- 1,040 Gbps switching, 774 Mpps
- MACsec, AVB, cloud managed
- Stacks up to 8 units
- Power supplies not installed
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks ExtremeSwitching
Model: 5720-24MW
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Switching Type: 5 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI
Performance: Forwarding rate: 774 Mpps, Stacking bandwidth: 400 Gbps, Switching bandwidth: 1040 Gbps
Stackable: Stackable
Features: Audio Video Bridging (AVB), Cloud managed, Full duplex mode, MACsec support, Non-blocking architecture
Max Units In A Stack: 8
Software Type: Base Software License
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 1/2.5/5GBase-T (PoE++)
Ports (2nd) Quantity: 2
Ports Type (2nd): 100 Gigabit QSFP28 (stacking)
Interface Provided: 1 x management (Gigabit LAN) RJ-45, 1 x micro-USB Type B console, 1 x serial (console) RJ-45, 2 x 100GBase-X QSFP28 stacking, 2 x USB Type A management, 24 x 1/2.5/5GBase-T RJ-45 PoE++ - 90 W
Expansion Slots: 1 (total) / 1 (free) x SSD, 1 (total) / 1 (free) x Versatile Interface Module (VIM)
Power Over Ethernet (PoE): PoE++
Power
Device Type: Internal power supply (not installed)
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 10 - 95% RH (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 10 - 95% RH (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.5 inch
Depth: 20.7 inch
Weight: 17.75 lbs
Certifications and Listing
Compliant Standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3bt, IEEE 802.3by, IEEE 802.3bz
Compliant Standards: 2014/30/EU, 2014/35/EU, ACMA RCM, ANATEL, AS/NZS 60950-1, AS/NZS CISPR 32, ASTM D3580, BSMI, CAN/CSA C22.2 No. 60950-1 Second Edition 2014, CDRH, China RoHS II (GB/T 26572-2011), CISPR 32 Class A, CQC, EAC, EMC, EN 300 386, EN 55032 Class A, EN 55035, EN 60825-1 Class 1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 62368-1, EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2, EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3, EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e, EN/ETSI 300 753 (1997-10), FCC CFR 47 Part 15 Class A, FCC CFR21 Part 1040.10, ICES-003 Class A, IEC 60950-1, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 62368-1, KCC, NOM, NRCS, REACH 1907/2006/CE, ROHS Directive 2011/65/EU, Taiwan RoHS CNS 15663 (2013.7), TEC, UL 60950-1, UL/CUL 62368-1, VCCI Class A, WEEE 2012/19/EU
ENERGY STAR Certified: No
