Product Information
Extreme Networks' 5720-48MW is a stackable managed switch with 48 multi-gig ports at 1, 2.5 or 5 Gbps, each able to deliver up to 90 W PoE++. Two 100G QSFP28 ports handle stacking up to eight units, and it supports MACsec and cloud management. Power supplies are not installed.
Key Features
- 48 x 1/2.5/5G RJ-45 PoE++ ports, 90 W
- 2 x 100G QSFP28 stacking ports
- Stack up to 8 units
- 1,280 Gbps switching bandwidth
- MACsec and cloud management
- Power supplies not installed
Product Information
Brand: Extreme Networks
Manufacturer: EXTREME NETWORKS
Product Line: Extreme Networks ExtremeSwitching
Model: 5720-48MW
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Purple
Network and Communication
Switching Type: 5 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI
Performance: Forwarding rate: 810 Mpps, Stacking bandwidth: 400 Gbps, Switching bandwidth: 1280 Gbps
Stackable: Stackable
Features: Audio Video Bridging (AVB), Cloud managed, Full duplex mode, MACsec support, Non-blocking architecture
Max Units In A Stack: 8
Software Type: Base Software License
Connectivity
Ports: 48
Port Quantity: 48
Port Type: 1/2.5/5GBase-T (PoE++)
Ports (2nd) Quantity: 2
Ports Type (2nd): 100 Gigabit QSFP28 (stacking)
Interface Provided: 1 x management (Gigabit LAN) RJ-45, 1 x micro-USB Type B console, 1 x serial (console) RJ-45, 2 x 100GBase-X QSFP28 stacking, 2 x USB Type A management, 48 x 1/2.5/5GBase-T RJ-45 PoE++ - 90 W
Expansion Slots: 1 (total) / 1 (free) x SSD, 1 (total) / 1 (free) x Versatile Interface Module (VIM)
Power Over Ethernet (PoE): PoE++
Power
Device Type: Internal power supply (not installed)
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 10 - 95% RH (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 10 - 95% RH (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.5 inch
Depth: 20.7 inch
Weight: 18.85 lbs
Certifications and Listing
Compliant Standards: IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3bt, IEEE 802.3by, IEEE 802.3bz
Compliant Standards: 2014/30/EU, 2014/35/EU, ACMA RCM, ANATEL, AS/NZS 60950-1, AS/NZS CISPR 32, ASTM D3580, BSMI, CAN/CSA C22.2 No. 60950-1 Second Edition 2014, CDRH, China RoHS II (GB/T 26572-2011), CISPR 32 Class A, CQC, EAC, EMC, EN 300 386, EN 55032 Class A, EN 55035, EN 60825-1 Class 1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 62368-1, EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2, EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3, EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e, EN/ETSI 300 753 (1997-10), FCC CFR 47 Part 15 Class A, FCC CFR21 Part 1040.10, ICES-003 Class A, IEC 60950-1, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 62368-1, KCC, NOM, NRCS, REACH 1907/2006/CE, ROHS Directive 2011/65/EU, Taiwan RoHS CNS 15663 (2013.7), TEC, UL 60950-1, UL/CUL 62368-1, VCCI Class A, WEEE 2012/19/EU
ENERGY STAR Certified: No
