Product Information
The Fortinet FN-TRAN-QSFP28-CWDM4 is a 100GBase-CWDM4 QSFP28 optic for Fortinet appliances with QSFP28 slots. It carries 100 Gigabit Ethernet (up to 103.1 Gbps) on four wavelengths between about 1271 and 1331 nm over single mode fiber with a duplex LC connector, reaching up to 1.2 miles (about 2 km). It is hot swappable, supports digital diagnostics monitoring and draws about 3.5 W. Listed systems include the FortiGate 3400E, 3401E, 3600E, 3601E, 3960E, 3980E and 7030E.
Key Features
- 100GBase-CWDM4
- Duplex LC single mode
- Reach up to 1.2 miles
- Digital diagnostics (DDM)
- Hot swappable
- For FortiGate QSFP28 ports
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet
Model: FN-TRAN-QSFP28-CWDM4
Product Type: QSFP28 transceiver module
Compatibility Specs: Fortinet FortiGate 3400E-DC, 3401E, 3401E-DC, 3600E, 3600E-DC, 3601E, 3960E, 3980E, 3980E-DC, 7030E-QSFP28, FG-7030E-QSFP28
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 100 Gigabit Ethernet
Cable Type: Ethernet 100GBase-CWDM4
Data Transfer Rate: 103.1 GBps
Max Transfer Distance: 1.2 miles
Optical Wave Length: 1264.5-1277.5 nm / 1284.5-1297.5 nm / 1304.5-1317.5 nm / 1324.5-1337.5 nm
Features: Auto-negotiation, Digital Diagnostics Monitoring (DDM), Hot swappable
Connectivity
Interface Provided: 1 x Ethernet 100GBase-CWDM4 - LC single-mode female x 2
Left Connector SD Type: LC single-mode
Power
Power Consumption Operational: 3.5 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Module
