Product Information
The Fortinet FN-TRAN-QSFP28-SR is a 100GBase-SR4 QSFP28 optic for Fortinet appliances with QSFP28 slots. It carries 100 Gigabit Ethernet (up to 103.1 Gbps) at 850 nm over multimode fiber with an MPO-12 connector, reaching up to 328 ft (about 100 m). It is hot swappable, supports digital diagnostics monitoring and draws about 3.5 W. Listed systems include the FortiGate 3400E, 3401E, 3600E, 3601E, 3960E, 3980E and 7030E.
Key Features
- 100GBase-SR4
- 850 nm, MPO-12 multimode
- Reach up to 328 ft
- Digital diagnostics (DDM)
- Hot swappable
- For FortiGate QSFP28 ports
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet
Model: FN-TRAN-QSFP28-SR
Product Type: QSFP28 transceiver module
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 100 Gigabit Ethernet
Cable Type: Ethernet 100GBase-SR4
Data Transfer Rate: 103.1 GBps
Max Transfer Distance: 328 ft
Optical Wave Length: 850 nm
Features: Auto-negotiation, Digital Diagnostics Monitoring (DDM), Hot swappable
Connectivity
Interface Provided: 1 x Ethernet 100GBase-SR4 - MPO-12 multi-mode female
Left Connector SD Type: MPO-12 multi-mode
Power
Power Consumption Operational: 3.5 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Module
Certifications and Listing
Compliant Standards #2: IEEE 802.3bm
Compliant Standards: OM4
Compliant Standards: IEEE 802.3bm
