Product Information
The Fortinet FortiAIOps 100G is a 1U AI driven network operations appliance that monitors and troubleshoots Fortinet networks; it is not a firewall. Per the spec it supports up to 30 FortiGates, 90 FortiSwitches, 180 FortiAPs, 30 FortiExtenders and 3,000 stations. It has four Gigabit RJ-45 ports, a console, two USB 3.0 ports and 3.84 TB of storage. The description says 90 FortiGates, please confirm.
Key Features
- AI network operations
- Up to 30 FortiGates
- 180 FortiAPs, 90 FortiSwitches
- 3,000 stations
- 4 x 1G RJ-45
- 1U, 3.84 TB storage
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiAIOps
Model: 100G
Product Type: Security appliance
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity: Maximum number of FortiExtender: 30, Maximum number of FortiGates: 30, Maximum number of FortiSwitch: 90, Number of FortiAP devices: 180, Stations: 3000
Features: Trusted Platform Module (TPM)
Connectivity
Interface Provided: 1 x console - RJ-45, 2 x USB 3.0 - Type A, 4 x 10/100/1000Base-T - RJ-45
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Consumption Operational: 98.5 watt
Memory and Processor
Hard Drive Form Factor (metric): M.2
Hard Drive Capacity: 3.84 TB
Hard Drive Form Factor: M.2
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% RH (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front to back airflow
Installed Quantity: 1
Dimensions and Weight
Height: 1.7 inch
Width: 17.2 inch
Depth: 16.5 inch
Weight: 12.06 lbs
Certifications and Listing
Compliant Standards: BSMI, C-mark, CB, FCC, ISED, RCM, UKCA, UL, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
