Product Information
The Fortinet FortiAIOps 500G is a 2U AI driven network operations appliance that monitors and troubleshoots large Fortinet networks; it is not a firewall. It supports up to 1,000 FortiGates, 3,000 FortiSwitches, 6,000 FortiAPs, 1,000 FortiExtenders and 25,000 stations. It has four Gigabit RJ-45 ports, two 10G SFP+ ports, a DB-9 console, two USB 3.0 ports, 2 TB of storage and redundant power.
Key Features
- AI network operations
- Up to 1,000 FortiGates
- 6,000 FortiAPs, 3,000 switches
- 25,000 stations
- 4 x 1G RJ-45 + 2 x 10G SFP+
- 2U, redundant power
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiAIOps
Model: 500G
Product Type: Security appliance
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity: Maximum number of FortiExtender: 1000, Maximum number of FortiGates: 1000, Maximum number of FortiSwitch: 3000, Number of FortiAP devices: 6000, Stations: 25000
Features: Trusted Platform Module (TPM)
Connectivity
Interface Provided: 1 x console - DB-9, 2 x 10GBase-T - SFP+, 2 x USB 3.0 - Type A, 4 x 10/100/1000Base-T - RJ-45
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Consumption Operational: 580 watt
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Memory and Processor
Hard Drive (2nd) Interface Type: Serial Attached SCSI
Hard Drive (2nd) Form Factor: 3.5"
Hard Drive (2nd) Form Factor (metric): 8.9 cm
Hard Drive Form Factor (metric): 6.4 cm
RAID Levels: RAID 0, RAID 1, RAID 10, RAID 5
Hot-Swap: Hot-swap
Hard Drive (2nd): Hot-swap
Hard Drive (2nd) Installed: 4
Hard Drive Capacity (2nd): 4 TB
Hard Drive Capacity: 2 TB
Hard Drive Form Factor: 2.5"
Port Expansion Hard Drive Type: SSD
Storage (2nd): HDD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% RH (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 2
Airflow Direction: Front to back airflow
Installed Quantity: 2
Dimensions and Weight
Height: 3.5 inch
Width: 17.3 inch
Depth: 29.3 inch
Weight: 50.26 lbs
Certifications and Listing
Compliant Standards: BSMI, CB, FCC, ISED, RCM, UL, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
