Product Information
The Fortinet FortiAnalyzer 3510G is a 4U high capacity log and analytics appliance for large Fortinet deployments, not a firewall. It handles 5,000 GB of logs per day, 90,000 logs per second collected and 60,000 analyzed, up to 10,000 VDOMs and 35 days of analytics. It has two 10G RJ-45 ports, two 25G SFP28 ports, 3.84 TB SSD storage and redundant power.
Key Features
- 5,000 GB of logs per day
- 90,000 logs/s collection
- Up to 10,000 VDOMs
- 2 x 10G RJ-45 + 2 x 25G SFP28
- Redundant power
- 4U rack mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiAnalyzer
Model: 3510G
Product Type: Network monitoring device
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 25 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity: GB/day of logs: 5000, Max number of days analytics: 35, Maximum VDOMs: 10000
Network Device: Analytic sustained rate: 60000 logs per second, Collector sustained rate: 90000 logs per second
Features: Content filtering, E-mail alert, Event log, Network monitoring, Syslog support, Trusted Platform Module (TPM)
Connectivity
Interface Provided: 2 x 10Gb Ethernet - RJ-45, 2 x 25Gb Ethernet - SFP28
Power
Device Type: Internal power supply
Power Consumption Operational: 983 watt
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Memory and Processor
RAID Levels: RAID 0, RAID 1, RAID 1 hot spare, RAID 10, RAID 5, RAID 5 hot spare, RAID 50, RAID 6, RAID 6 hot spare, RAID 60
Hard Drive (2nd) Installed: 24
Hard Drive Capacity (2nd): 4 TB
Hard Drive Capacity: 3.84 TB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 4
Airflow Direction: Front to back airflow
Installed Quantity: 2
Dimensions and Weight
Height: 7 inch
Width: 17.2 inch
Depth: 27.5 inch
Weight: 65.04 lbs
Certifications and Listing
Compliant Standards: CB, cUL, FCC Part 15 A, RCM, UL, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
