Product Information
The Fortinet FortiExtender 211G is a 4G / 3G cellular WAN extender with eSIM support and three external SMA antennas. It has one Gigabit WAN and four Gigabit LAN ports, USB and Bluetooth 5.0 LE, draws about 9.18 W, and can be desk or wall mounted. The power adapter is not included. This is a cellular router, not an access point.
Key Features
- 4G LTE / 3G WWAN, eSIM
- 1 WAN + 4 LAN Gigabit ports
- 3 external SMA antennas
- USB, Bluetooth 5.0 LE
- Desk or wall mount
- Power adapter not included
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiExtender
Model: 211G
Product Type: Router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Country: Global
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management: CLI
Routing Protocol: VRRP, VXLAN
Bridge & Router: Lan-Extension throughput: 600 Mbps, LAN-to-WAN throughput: 900 Mbps, LTE downlink bandwidth: 600 Mbps, LTE uplink bandwidth: 150 Mbps, Maximum throughput (LAN): 950 Mbps, VPN throughput (IPSec, 5G/LTE): 170 Mbps, VPN throughput (IPSec, wired): 890 Mbps
Capacity: Wan uplinks supported: 1
Integrated Switch: 4-port switch
Wireless LAN: Bluetooth 5.0 LE
Cellular Data Connectivity Technology: HSPA+, LTE, UMTS, WCDMA
IoT Communications Technology: Bluetooth 5.0 BLE
Internet of Things (IoT) Compatible: Yes
Antennas: 3
Antenna Form Factor: External
Key Features: Firewall, USB port, VPN support
Features: 2x2 MIMO technology, 4x4 MIMO technology, Cloud managed, eSIM support, High Availability, Reset button, SD-WAN support, Wi-Fi Diversity
Connectivity
Interface Provided: Antenna: 1 x, Antenna: 3 x SMA, LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45, USB 2.0: 1 x Type A, WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Expansion Slots: 2 (total) / 2 (free) x Micro-SIM
WAN Ports Quantity: 1
Power
Device Type: External power adapter / power injector (not included)
Power Consumption Operational: 9.18 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95%
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, Wall-mountable
Built-in Devices: GNSS receiver
Dimensions and Weight
Height: 1.5 inch
Width: 6.2 inch
Depth: 6.2 inch
Weight: 14.46 ounce
Certifications and Listing
Compliant Standards: EMC 2014/30/EU, EN 300 328, EN 301 489-1, EN 301 489-17, EN 301 489-19, EN 301 489-52, EN 301 908-1, EN 301 908-2, EN 301 908-25, EN 301 908-3, EN 303 413, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 62368-1, EN IEC 62311, FCC 2.1091, FCC Part 15 B, FCC Part 15 C, ICES-003, IEC/EN 62368-1, LVD 2014/35/EU, PTCRB, RED 2014/53/EU, RSS-102, RSS-247, UL/CSA 62368-1
Compliant Standards: IEEE 802.3at
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
