Product Information
This FortiGate 100F bundle includes FortiCare 24x7 Comprehensive support and FortiGuard services for 1 year. The 100F is a 1U firewall rated at 20 Gbps firewall, 11.5 Gbps IPsec VPN, 1.6 Gbps IPS and 800 Mbps NGFW, with up to 2,500 overlay tunnels. Quick specs list twelve Gigabit RJ-45 ports, two RJ-45 WAN ports, four shared RJ-45/SFP ports and eight SFP slots, while the spec lists different port counts, please confirm. It also has two 10G SFP+ ports, a DMZ port, a management port and dual power supplies.
Key Features
- 1 yr 24x7 FortiCare + FortiGuard
- 20 Gbps firewall
- 11.5 Gbps IPsec VPN
- 2 x 10G SFP+
- Dual power supplies
- 1U rack mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 100F
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity: Maximum overlay tunnels: 2500
Network Device: Firewall throughput: 20 Gbps, IPS throughput: 1.6 Gbps, NGFW throughput: 800 Mbps, SSL inspection throughput: 1 Gbps, Threat protection throughput: 700 Mbps, VPN throughput (IPSec): 11.5 Gbps
Features: Firewall protection
Bundled Services: 1 year FortiCare 24X7 Comprehensive Support + 1 year FortiGuard
Connectivity
Interface Provided: 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 1 x network - RJ-45 (DMZ), 1 x USB 3.0, 10 x Ethernet 1000 - SFP (mini-GBIC), 2 x 10Gb Ethernet - SFP+, 20 x 1000Base-T - RJ-45
Power
Device Type: Internal power supply
Power Supplies Installed: 2
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Physical Characteristics
Form Factor: External
Certifications and Listing
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
